Samson 3767 - Installing the Limit Contacts; Installing a Solenoid Valve

48 EB8355-2EN
Convertingandretrottingthepositioner
6.2 Installingthelimitcontacts
Accessories: Limit switch retrot kit depend-
ing on model index 3767-xxxxxxxxxx.04
Order no. 1400-8810 for index .06 or
higher
Order no. 1400-7573 for index .04/.05
Order no. 1400-6389 for index .03
1. Unscrewthebracketwithplate(1).
2. Removethescrews(2)andreplacethe
entiresetpointcalibrator(3)withacali-
bratorincludinglimitcontacts.Makesure
theO-ringisinsertedintothehousing.
3. Attachtheterminalblockforthelimitsig-
nals41/42and51/52intheterminal
base.
4. Guidetheconnectingcabletothetermi-
nals and fasten.
(brown=+,blue=–)
5. Refastenthebracketwithplate(1)and
sticktheadhesivelabelforthelimit
switches on the housing cover.
6. Screwadditionalcableglandontothe
housing.
6.3 Installingasolenoidvalve
Accessories: Solenoid valve retrot kit
Order no. 1400-7712 for index .05 or
lower
Order no. 1400-8808 for index .06
1. Pushtheplate(5)tooneside.
2. Unscrewthefourscrews(7).Liftoffthe
blackcoverwiththerubbergasketand
insertthesolenoidvalve(6).Therubber
gasket with the restriction is located in
the rear of the solenoid valve.
3. Unscrewtheplate(1).
1 2 23
4
5
6789
10
Fig.17:Installing the limit switches and solenoid valve
