34 EB8355-2EN
Connections
4 Connections
4.1 Pneumaticconnections
The pneumatic connections are optionally
designedasaborewith¼NPTorG¼
thread.Customaryttingsformetalorcop-
pertubingorplastichosescanbeused.
NOTICE
The supply air must be dry and free
from oil and dust. The maintenance
instructions for upstream pressure
reducing stations must be observed.
Blow through all air pipes and hoses
thoroughly before connecting them.
If the positioner is attached directly to the
Type3277Actuator,theconnectionofthe
positioner's output pressure to the actuator is
xed.Forattachmentaccordingto
IEC60534-6(NAMUR),thesignalpressure
canberoutedtoeitherthetoporbottom
diaphragmchamberoftheactuator,
dependingontheactuator'sfail-safeaction
"actuator stem extends" or "actuator stem
retracts".
Exhaustair
Modelswithindex3767-x...x.03 and higher
are equipped with a hinged cover without its
own exhaust air hole. The exhaust air con-
nections for these models are included in the
accessories.
The vent plug is located on the plastic cover
of the actuator for direct attachment, where-
as for NAMUR attachment, it is located on
the adapter housing. The vent plug is located
on the intermediate piece or reversing ampli-
erforattachmenttorotaryactuators.
NOTICE
If you intend to replace older models
with index 3767-x...x.02 or lower,
the mounting parts may need to be
replaced as well.
4.1.1 Pressuregauges
To precisely tune the positioner, we recom-
mend installing pressure gauges for the sup-
ply air and signal pressure.
The required parts are listed as accessories
inTable4,Table5andTable7.
4.1.2 Supplypressure
The required supply air pressure depends on
thebenchrangeandtheactuator'soperat-
ingdirection(fail-safeaction).
Thebenchrangeiswrittenonthenameplate
either as the spring range or signal pressure
range. The operating direction is marked FA
or FE,orbyasymbol.
Actuatorstemextends(FA):
Fail-close
(forglobeandanglevalves)
Required supply pressure =
Upperbenchrangevalue+0.2bar,
atleast1.4bar.
