Samson 3767 - Page 33

EB8355-2EN 33
Mountingoncontrolvalves
1.3 1.2 1.1 1
Output 38 Supply 9
A
1
1.5 1.6
Z
A
2
1.4
A
1
A
2
Output 38 Supply 9
1.3 1.21.1
1.6
Z
A
1
From the positioner
Control signals to the actuator
1 Reversingamplier
1.1 Special screws
1.2 Gasket
1.3 Special nuts
1.4 Rubberseal
1.5 Sealing plug
1.6 Filter
Fig.11:Mounting a reversing amplier
