Servicingexplosion-protecteddevices
4. Attachtheterminalblock(10)fortheso-
lenoidvalveintheterminalbase.
5. Insertthepanel(9)attherearofthepo-
sitioner and attach it to the set point cali-
bratorusingtwoscrews.
6. Guidetheconnectingcabledownbehind
the mounted panel of the set point cali-
bratorandupagaintoterminals81/82
and fasten.
(brown=+,blue=–)
7. Screwonthebracketwithplate(1).
8. Screwadditionalcableglandontothe
housing.
6.4 Removingthesolenoid
valve
Accessories: Retrot kit containing cover for
solenoid valve opening: order no. 1400-
6949
1. Unscrewbracketwithplate(1).Remove
theconnectingcableofthesolenoid
valve from terminals 81/82.
2. Unscrewthetwoscrews(7)thatarenot
sealed with paint and remove the sole-
noidvalvewithitsconnectingcable.
3. Placetherubbergasketonthespigotof
the cover and screw it into the housing.
4. Screwonthebracketwithplate(1).
7 Servicingexplosion-protected
devices
If a part of the device on which the explosion
protectionisbasedneedstobeserviced,the
devicemustnotbeputbackintooperation
untilaqualiedinspectorhasassesseditac-
cording to explosion protection require-
ments,hasissuedaninspectioncerticateor
given the device a mark of conformity.
Inspectionbyaqualiedinspectorisnotre-
quired if the manufacturer performs a rou-
tinetestonthedevicebeforeputtingitback
into operation. Document the passing of the
routinetestbyattachingamarkofconformi-
ty to the device.
Inspectionbyaqualiedinspectorisnotre-
quired if the manufacturer performs a rou-
tinetestonthedevicebeforeputtingitback
into operation. Document the passing of the
routinetestbyattachingamarkofconformi-
tytothedevice.Replaceexplosion-protected
componentsonlywithoriginal,routine-tested
componentsbythemanufacturer.
Devicesthathavealreadybeenusedout-
sidehazardousareasandareintendedfor
futureuseinsidehazardousareasmust
complywiththesafetyrequirementsplaced
onserviceddevices.Beforebeingoperated
insidehazardousareas,testthedevicesac-
cordingtothespecicationsforservicing
explosion-protecteddevices.Observe
EN60079-17duringservicing.
