Product Specifications
Samsung Electronics 2-13
Model
AVXC4H045E6
ND0454H666
AVXC4H056E6
ND0564H666
AVXC4H071E6
ND0714H666
AVXC4H090E6
ND0904H666
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
Heat Pump Heat Pump HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 4.5 5.6 7.1 9.0
Btu/h 15,300 19,100 24,200 30,700
Heating*
3)
kW 5.0 6.3 8.0 10.0
Btu/h 17,000 21,400 27,200 34,100
Condensate (with High fan speed) Liters/h 2.23 2.71 3.51 4.46
Power
Input W 40 40 45 50
Running Current A 0.19 0.19 0.21 0.23
Sound Level Sound Pressure (High/Low)*
4)
dB(A) 34 / 29 34 / 29 36 / 30 39 / 32
Fan
Type - Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor
Model - SIC-67FV-F135-1 SIC-67FV-F135-1 SIC-67FV-F135-1 SIC-67FV-F135-1
Type - BLDC BLDC BLDC BLDC
Output W *5) *5) *5) *5)
Airflow Rate
Cooling (High) m
3
/min 14.5 14.5 17 19.5
Heating (High) m
3
/min 16.5 16.5 18.5 21.5
Refrigerant
Type - R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 9.52 9.52
Gas (Flare) ø, mm 12.7 12.7 15.88 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight
Net Weight kg 25.0 25.0 25.0 25.0
Shipping Weight kg 31.0 31.0 31.0 31.0
Dimensions
Net Dimensions (W x H x D) mm 840x218x840 840x218x840 840x218x840 840x218x840
Shipping Dimensions (W x H x D) mm 926x280x926 926x280x926 926x280x926 926x280x926
Panel Size
Model - P4SMA P4SMA P4SMA P4SMA
Net Weight kg 7.0 7.0 7.0 7.0
Shipping Weight kg 10.3 10.3 10.3 10.3
Net Dimensions (W x H x D) mm 950x35x950 950x35x950 950x35x950 950x35x950
Shipping Dimensions (W x H x D) mm 1,042x103x1,042 1,042x103x1,042 1,042x103x1,042 1,042x103x1,042
Functions
Auto Restart - O O O O
Auto Swing - O O O O
Group/Individual Control - O O O O
External Contact Control - O O O O
Trouble Shooting by LED - O O O O
Standard
Accessories
Installation Manual - O O O O
Operation Manual - X X X X
Pattern Sheet for Installation - O O O O
Flexible Drain Hose - O O O O
Filter / Safety Grille - Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille
Drain Pump (Pumping speed, lift) ℓ/h,mm 24, 750 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-BH01 MR-BH01 MR-BH01 MR-BH01
Wired Remote
Controller
Simplified - MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00
Standard - MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01
Premium - MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14
Indoor Unit(cont.)
Q4 way cassette
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
