Samsung AVXTJH028EE - Assy Pcb Main Hub

PCB Diagram and Parts List
Samsung Electronics 6-48
ASS'Y PCB MAIN HUB (cont.)
■ AC (cont.)
①
#1: S/W L
#2: S/W L
②
#1: L
#3: N
③
#1: EVI1(L)
#3: EVI2(L)
#5: EVI3(L)
#7,8,9: N
④
#1: OIL V/V1(L)
#3: OIL V/V2(L)
#5: OIL V/V3(L)
#7,8,9: N
⑤
#1: CCH3(L)
#2: N
⑥
#1: CCH2(L)
#2: N
⑦
#1: CCH1(L)
#2: N
⑧
#1: ACCUM CCH(L)
#2: N
⑨
#1: LIQUID1(L)
#2: N
⑩
#1: LIQUID1(L)
#2: N
⑪
#1: OD EEV(L)
#2: N
⑫
#1: EVI(L)
#2: N
⑬
#1: HOTGAS(L)
#2: N
⑭
#1: COOLING(L)
#2: N
⑮
#1: OILGAS(L)
#2: N
⑯
#1: 4WAY(L)
#2: N
⑰
#1: PWM(L)
#2: N
CN701 – High Pressure S/W CN70 - AC 220V CN91-1 - EVI1,2,3 V/V CN75 - OIL1,2,3, V/V
CN73 - CCH3 V/V CN72 - CCH2 V/V CN71 - CCH1 V/V CN74 - ACCUM CCH V/V
CN85 - LIQUID1 V/V CN86 - LIQUID2 V/V CN88 - OD EEV V/V
HOTGAS V/V COOLING V/V OILGAS V/V
PWM V/V
CN89 - EVI V/V
4WAY V/V
