Samsung AVXTJH028EE - Assy Pcb Sub Sensor Ct Low

PCB Diagram and Parts List
6-57 Samsung Electronics
①
#1 : 5V
#2 : COMP3 Current SENSING
#3 : RELAY4 Signal
#4 : RELAY5 Signal
#5 : 12V
#6 : GND
②
#1 : R
#2 : S
#3 : T
③
#1 : R
#2 : S
#3 : T
④
#1 : R
#3 : S
#5 : T
CN201 – COMP2 Power CN101 – COMP1 Power CN401- UP CT TO LOW CT CN402 - CT TO MAIN
6-2-7 ASS'Y PCB SUB SENSOR CT LOW
1 2 3 4
