Samsung AVXTJH028EE - Wall Mounted Type(Neo Forte with EEV)

Wiring Diagram
7-16 Samsung Electronics
7-1-15 Wall Mounted type(Neo Forte with EEV)
Display Part
This Document can not be used without Samsung’s authorization.
Indoor
Eva. In
Eva. Out
Sensor Part
Fan Motor Part
Rouver Control
Part
EEV Control Part
