Exploded Views and Parts List
Samsung Electronics 5-4
■ Parts List (ND0561/0711HXE✳ Series)
No. SA/SNADescription Specification
Q'TY
Code No.
0561 0711
1 DB61-03127A BRACKET-PAN SGCC-M,1.0,12,20 2 2 SNA
2 DB90-05154A ASS'Y CABINET IN-SUB ASS'Y 1 1 SA
2-1 DB64-02357A CABINET-IN ABS,T3.0,400.3,1236,BKT 1 1 SNA
2-2 DB63-02381A CABINET-CUSHION EPS,T5,351,985.9,GRAY 1 1 SNA
3 DB61-03836A PLATE-HANGER SGCC-M,T0.8,69,75.5,WHITE 4 4 SA
4 DB94-00258A ASS'Y BEARING CR,BLK,G-PJT 1 1 SA
4-1 DB73-00128A RUBBER-BEARING G-P/J,CR,55,BLK 1 1 SNA
4-2 DB94-40007A ASS'Y BEARING ASS'Y,POLYSLIDER-PG5 1 1 SNA
5 DB94-02274A ASS'Y-DRAIN SOCKET ASS'Y 1 1 SA
5-1 DB62-04236A VALVE CHECK ASS'Y,72.5 1 1 SA
6 DB61-03834A PLATE-COVER CONTROL SGCC-M,T0.5,478,115.6 1 1 SA
7 DB93-08955B ASS'Y PCB MAIN ASS'Y,FR-4,1.6T,320mmx75mm 1 1 SA
8 DB61-03829A CASE-CONTROL ABS,3.0T,476,90,BLK 1 1 SA
9 DB61-03835A PLATE-CASE CONTROL SGCC-M,T0.7,487.4,47.7 1 1 SA
10 DB63-02462A COVER-WIRE HOLE ABS,2,55,35.5,WHT 1 1 SNA
11 DB65-00274B ASS'Y-TERMINAL BLOCK 1(L),2(N) 1 1 SA
12 DB65-00277A ASS'Y-TERMINAL BLOCK F1,F2,V1,V2,F3,F4 1 1 SA
13 DB31-00332B MOTOR FAN SIC-55CVL-F158-1,0V,E,YH396-06VRT/YT396B-RT,250 1 1 SA
14 DB63-02379A COVER MOTOR ABS,T2.0,100,123.9,BLK 1 1 SA
15 DB94-00118A ASS'Y FAN-CROSS R ASS'Y 1 1 SA
15-1 DB94-00119A ASS'Y FAN-CROSS L ASS'Y 1 1 SA
16 DB67-00833A DRAIN-PUMP PBT,1.0,WHITE 1 1 SA
17 DB69-00137A BAND-RING STS304,T1.5,PI14 1 1 SNA
18 DB73-00494A RUBBER-BASE PUMP NBR,-,30,32.5,BLK 1 1 SA
19 DB73-00391D RUBBER-CAP PUMP NBR,30,BLK 1 1 SNA
20 DB63-02265A COVER-PUMP ABS,T2.0,82.5,40.5,WHT 1 1 SA
21 DB95-01359F ASS'Y-SENSOR FLOAT FLOAT SWITCH,8.5mm,GAUSS 26G,180mm 1 1 SA
22 DB94-02299D ASS'Y DRAIN PAN ASS'Y 1 1 SA
23 DB73-00306A RUBBER-CAP DRAIN SOCKET NBR,Ø31,BLK 1 1 SA
24 DB94-02275B ASS'Y DRAIN PAN-SUB ASS'Y 1 1 SNA
25 DB96-13504A ASS'Y EVAP-UNIT ASS'Y - 1 SA
DB96-13504B ASS'Y EVAP-UNIT ASS'Y 1 - SA
25-1 DB60-30010A NUT-FLARE HEX,1/4",7/16-20UNF 1 - SA
DB60-30010B NUT-FLARE HEX,3/8",5/8-18UNF - 1 SA
25-2 DB60-30010C NUT-FLARE HEX,1/2",3/4-16UNF 1 - SA
DB60-30010D NUT-FLARE HEX,5/8",7/8-14UNF - 1 SA
26 DB94-01904A ASS'Y DRAIN-HOSE INSTALL ASS'Y 1 1 SNA
26-1 DB62-04783A INSULATION-DRAIN FOAM-PE,T12,20,165,GRAY 1 1 SNA
26-2 DB62-04783A INSULATION DRAIN-HOSE FOAM-PE,T12,20,165,GREY,NON FLAmmABILITY 1 1 SNA
26-3 DB63-00237A GROMMET-HANGER NBR 8 8 SNA
26-4 DB67-00285A DRAIN HOSE-SOCKET POM,T3 1 1 SNA
26-5 DB72-00401C INSULATION-JOINT OUT FOAM-PE,T3,W200,L200,GREY 2 2 SNA
26-6 DB94-01258C ASS'Y DRAIN-HOSE JOINT ASS'Y 1 1 SA
26-6-1 DB67-00923A DRAIN HOSE-HOUSING GREEN 2 2 SNA
26-6-2 DB67-00336E HOSE DRAIN-PVC SOFT PVC,14,20,3,GRAY 1 1 SNA
26-6-3 DB67-00805B DRAIN HOSE-JOINT B PVC,T3.0,NORMAL 1 1 SA
27 DB90-04939A ASS'Y COVER-CABI OUTLET ASS'Y,ABS,BLK,30,FOAM-PU,L50,W10,T5 1 1 SNA
28 DB73-00510A RUBBER CABINET-WIRE NBR,BLK,28 1 1 SNA
