Exploded Views and Parts List
Samsung Electronics 5-8
■ Parts List
No. SA/SNADescription Specification
Q'TY
Code No.
PC1BUSEA
1 DB64-02270A PANEL FRONT-BASE ABS,T2.0,1410,500,WHITE 1 SA
2 DB63-02295A COVER PANEL FRONT ABS,T2.5,45,90,WHT 2 SA
3 DB90-04996A ASS'Y COVER SCREW ABS+SEAL 4 SA
4 DB61-02894A HOLDER-PUSH LATCH POM,PC+PE,11.9,12.9,21,BLK 6 SA
5 DB61-03854A GUIDE-FILTER S ABS,T2.0,185,475,GRAY 1 SA
6 DB61-03853A GUIDE-FILTER L ABS,T2.0,185,541.5,GRAY 1 SA
7 DB63-02277A FILTER-AIR INLET S ABS,T2.0,184,470,GRAY 1 SA
8 DB63-02276A FILTER-AIR INLET L ABS,T2.0,184,530,GRAY 1 SA
9 DB65-00023A CLIP-WIRE-ASS'Y NYLON 2 SNA
10 DB62-07241A SEAL-PANEL SIDE LF FOAM-PE,GRAY,T10,32,87 1 SNA
11 DB62-07240A SEAL-PANEL SIDE RH FOAM-PE,GRAY,T10,32,84 1 SNA
12 DB66-01402A BLADE-H ABS,T2.0,68.3,WHT 1 SA
13 DB64-00237A PANEL-DISPLAY LED PC 1 SA
14 DB64-01760A WINDOW-DISPLAY PCB PC,1.5,40,40,MILKY WHT 1 SNA
15 DB63-02275A COVER-DISPLAY PCB ABS,T2.0,112,90,NATURAL 1 SA
16 DB93-07960A ASS'Y PCB SUB-DISPLAY ASS'Y 1 SNA
17 DB61-03856A BRACKET MOTOR-BLADE H SGCC-M,T1,50,33.7,NATURAL 1 SA
18 DB31-00369B MOTOR STEP DC12V,10~40,DC12V,1500gf.cm 1 SA
19 DB61-03855A GUIDE-AIR OUTLET ABS,T2.0,38,1103,GRAY 1 SA
20 DB61-03851A PLATE-GUIDE PANEL SGCC-M,T1.7,22.3,1095 1 SA
21 DB61-03850A GUIDE-CUSHION AIROUT EPS,T10,32,1125,WHT 1 SA
22 DB62-07242A SEAL-PANEL OUT EPDM,BLK,T10,86,1140 1 SNA
23 6002-000635 SCREW-TAPPING PH,2S,M4,L8 2 SNA
24 6002-000231 SCREW-TAPPING TH,2S,M4,L12 10 SNA
25 DB64-02271A GRILLE-STANDARD ABS,T2.5,228,1337,WHT 1 SA
$9;&6+B$BaLQGG
To Next Page
