Exploded Views and Parts List
Samsung Electronics 5-14
■ Parts List
No. SA/SNADescription Specification
Q'TY
Code No.
AVXC4H045E✳
AVXC4H056E✳
ND0454H✳✳✳
ND0564H✳✳✳
1 DB63-01480A GUARD-SAFETY CH140EAMC,HSWR 1 1 SNA
2 DB63-01481A COVER-CONTROL CH140EAMC,ABC 1 1 SNA
3 DB93-05981B ASS'Y MAIN PCB CH140EAMC 1 1 SNA
4 DB93-04119B ASS'Y PCB SUB-POWER CH140EAMC 1 1 SNA
5 DB93-05254A ASS'Y CONTROL IN ASS'Y 1 1 SNA
5-1 DB61-03092A BASE CONRTROL ABS,V0 1 1 SNA
5-2 DB61-02501A TIE MOUNTS NYLON66 2 2 SNA
5-3 DB61-02700A BRACKET EARTH WIRE SGCC-M 1 1 SNA
5-4 DB65-00029M TERMINAL BLOCK 4P ASS'Y,6P 1 1 SA
5-5 DB65-00029X TERMINAL BLOCK 6P ASS'Y,4P 1 1 SA
5-6 DB61-02765A HOLDER SENSOR PP 1 1 SNA
5-7 6501-001052 REUSABLE CABLE TIES NYLON66 2 2 SNA
6 DB94-01062A ASS'Y CUSHION DRAIN ASS'Y,EPS,V0 1 1 SNA
7 DB61-01783A BRACKET WASHER FAN SGCC-M 1 1 SNA
8 DB67-00804A ASS'Y FAN TURBO ABS+GF10% 1 1 SNA
9 DB64-01734A CABI SIDE SGCC-M 2 2 SNA
10 DB90-02692A ASS'Y COVER PIPE ASS'Y 1 1 SNA
11 DB90-03189A ASS'Y CABI FEONT ASS'Y,SGCC-M 1 1 SNA
12 DB90-01950B ASS'Y COVER DRAIN PUMP ASS'Y 1 1 SNA
13 DB94-01389A ASS'Y HOSE DRAIN ASS'Y 1 1 SNA
14 DB61-03093A HOLDER EVAP STS301 2 2 SNA
15 DB96-08027B ASS'Y EVAP UNIT ASS'Y 1 - SNA
DB96-08027A ASS'Y EVAP UNIT ASS'Y - 1 SNA
16 DB90-03190A ASS'Y CABI BACK ASS'Y,SGCC-M 1 1 SNA
17 DB90-02090B SCREW PUMP M5X30 - - SA
18 DB94-01381A ASS'Y DRAIN PUMP ASS'Y 1 1 SNA
18-1 DB34-00063A SWITCH FLOAT ASS'Y 1 1 SNA
18-2 DB73-00345A RUBBER PUMP NBR 3 3 SNA
18-3 DB61-02709A BRACKET DRAIN PUMP SGCC-M 1 1 SNA
18-4 DB67-00790A DRAIN PUMP ASS'Y 1 1 SNA
19 DB61-02349A CLIP BRUSH NYLON 66 - - SNA
20 DB97-05920A ASS'Y CUSHION BASE ASS'Y,EPS,V0 1 1 SNA
21 DB31-00439A MOTOR INDOOR BLDC 1 1 SA
22 DB90-03188A ASS'Y BRACKET MOTOR ASS'Y - - SNA
23 DB93-07219A CONNECT MOTOR FAN SUB ASS'Y 1 1 SNA
24 DB32-00169A THERMISTOR IN ASS'Y 1 1 SA
25 DB32-00141A THERMISTOR EVAP ASS'Y 1 1 SNA
26 DB94-01389A ASS'Y DRAIN HOSE ASS'Y 1 1 SNA
27 DB90-02689B ASS'Y CABI BASE ASS'YSGCC-M 1 1 SNA
AVXC4H071E✳
AVXC4H090E✳
ND0714H✳✳✳
ND0904H✳✳✳
