Exploded Views and Parts List
Samsung Electronics 5-28
■ Parts List
Q'TY
AVXDSH022E✳
ND022LHXE✳
AVXDSH028E✳
ND028LHXE✳
AVXDSH036E✳
ND036LHXE✳
No.
Code No.
Description Specification
SA/SNA
1 DB90-02014A ASS'Y CABI BASE ASS'Y 1 1 1 SA
2 DB90-03262A ASS'Y CABI SIDE LF ASS'Y 1 1 1 SA
3 DB90-01951A ASS'Y CABI SIDE RH ASS'Y 1 1 1 SA
4 DB90-01938A ASS'Y COVER PIPE ASS'Y 1 1 1 SA
5 DB90-01950A ASS'Y COVER DRAIN PUMP ABS T2.0 1 1 1 SA
6 DB64-01326A CABI TOP MOTOR SGCC-M, T0.8 1 1 1 SA
7 DB90-02069D ASS'Y CABI TOP EVAP ASS'Y 1 1 1 SA
8 DB61-02274A PLATE HANGER SGCC-M, T2.0 2 2 2 SA
9 DB94-00712A ASS'Y BRACKET OUTLET ASS'Y 1 1 1 SA
10 DB61-02277A BRACKET OUTLET SUB SGCC-M, T0.8 1 1 1 SA
11 DB97-03791A ASS'Y CUSHION BASE ASS'Y 1 1 1 SNA
12 DB96-05330C ASS'Y EVAP UNIT ASS'Y 1 1 1 SA
13 DB90-01978A ASS'Y SUPPORT EVAP LF ASS'Y 1 1 1 SA
14 DB90-01946A ASS'Y SUPPORT EVAP RH ASS'Y 1 1 1 SA
15 DB94-00768A ASS'Y PARTITION ASS'Y 1 1 1 SA
16 DB61-02282A BRACKET MOTOR SGCC-M T2.0 1 1 1 SA
17 DB99-00669A BAND MOTOR SINYA 4 4 4 SA
18 DB31-00312A MOTOR SINYA, SSR, PID 1 1 1 SA
19 DB67-00565A BLOWER ASS'Y, ABS, TORSIONAL BUSH 2 2 2 SA
20 DB90-01947A ASS'Y CASE BLOWER UPPER ASS'Y 2 2 2 SA
21 DB90-01948A ASS'Y CASE BLOWER BOTTOM ASS'Y 2 2 2 SA
22 DB94-01007B ASS'Y DRAIN PAN ASS'Y 1 1 1 SNA
23 DB93-03321K ASS'Y CONTROL IN ASS'Y 1 1 1 SA
23-1 DB90-01941B ASS'Y CASE CONTROL ASS'Y 1 1 1 SA
23-2 DB61-02287A CASE PCB ABS T2.5 1 1 1 SA
23-3 DB63-01237A COVER CONTROL SGCC-M T0.5 1 1 1 SA
23-4 DB65-00105L TERMINAL BLOCK 6P 6P, POWER 1 1 1 SNA
23-5 DB65-00105M TERMINAL BLOCK 6P 6P, COMMUNICATION 1 1 1 SNA
23-6 DB26-00080A TRANS POWER 230V, 50HZ 1 1 1 SA
23-7 2301-001370 CAPACITOR 450V 1.5μF 1 1 1 SA
23-8 DB93-05959J ASS'Y PCB MAIN ASS'Y 1 1 1 SA
24 DB32-00142A ASS'Y THERMISTOR ASS'Y 1 1 1 SA
25 DB32-00141A THERMISTOR EVAP ASS'Y 1 1 1 SA
26 DB63-01299E ASS'Y FILTER ASS'Y 1 1 1 SA
$9;&6+B$BaLQGG
To Next Page
