Exploded Views and Parts List
Samsung Electronics 5-30
■ Parts List
No.
SA/SNA
Description
Specification
Q'TY
Code No.
1 DB90-02160A ASS'Y CABI BASE SGCC-M T0.8 1 1 SA
2 DB90-03262B ASS'Y CABI SIDE LF SGCC-M T0.8 1 1 SA
3 DB90-01951A ASS'Y CABI SIDE RH SGCC-M T0.8 1 1 SA
4 DB90-01938A ASS'Y COVER PIPE SGCC-M T0.5 1 1 SA
5 DB90-01950A ASS'Y COVER DRAIN PUMP SLIM DUCT 1 1 SA
6 DB64-01345A CABI TOP MOTOR SGCC-M,T0.8 1 1 SA
7 DB90-02161B ASS'Y CABI TOP EVAP SGCC-M,T0.8 1 1 SA
8 DB61-02274A PLATER HANGER SGCC-M,T2.0 2 2 SA
9 DB97-03796A ASS'Y BRACKET OUTLET SGCC-M,T0.8 1 1 SA
10 DB61-02322A BRACKET OUTLET SUB SGCC-M,T0.8 1 1 SA
11 DB97-03792A ASS'Y CUSHION BASE A EPS 25 1 1 SNA
12 DB97-03791A ASS'Y CUSHION BASE B EPS 25 1 1 SNA
13 DB96-05785B ASS'Y EVAP UNIT ASS'Y 1 - SA
DB96-05785A ASS'Y EVAP UNIT ASS'Y - 1 SA
14 DB90-01978A ASS'Y SUPPORT EVAP LF SGCC-M,T0.8 1 1 SA
15 DB90-01946A ASS'Y SUPPORT EVAP RH SGCC-M,T0.8 1 1 SA
16 DB94-00809A ASS'Y PARTITION SGCC-M,T1.0 1 1 SA
17 DB61-02282A BRACKET MOTOR SGCC-M,T2.0 1 1 SA
18 DB97-03800A BAND MOTOR SINYA 1 1 SA
19 DB31-00314C MOTOR SINYA,60Hz 1 1 SA
20 DB66-01007A MOTOR SHAFT SINYA 1 1 SNA
21 DB94-00759A MOLD BEARING ASS'Y 1 1 SA
22 DB67-00581A CAP BEARING SGCC-M,T0.8 1 1 SNA
23 DB73-00285A RUBBER SHAFT CR V0 1 1 SNA
24 DB96-04902A COUPLER ASS'Y 1 1 SA
25 DB67-00565A BLOWER A ASS'Y,ABS 1 1 SA
26 DB67-00576A BLOWER B ASS'Y,ABS 2 2 SA
27 DB90-01947A ASS'Y CASE BLOWER UPPER ASS'Y ABS 3 3 SA
28 DB90-01948A ASS'Y CASE BLOWER BOTTOM ASS'Y ABS 3 3 SA
29 DB94-01007A ASS'Y DRAIN ASS'Y 1 1 SNA
30 DB93-03321E ASS'Y CONTROL PART ASS'Y 1 1 SA
30-1 DB90-01941A ASS'Y CASE CONTROL ASS'Y 1 1 SA
30-2 DB61-02287A CASE PCB ABS V0,T2.5,-,-,-,- 1 1 SA
30-3 2301-001379 CAPACITOR 450V,4uF 1 1 SA
30-4 DB65-00105L TERMINAL BLOCK 6P 6P,POWER 1 1 SNA
30-5 DB65-00105M TERMINAL BLOCK 6P 6P,COMMUNICATION 1 1 SNA
30-6 DB26-10070G TRANS POWER 60Hz 1 1 SNA
31 DB32-00142A ASS'Y THERMISTOR ASS'Y 1 1 SA
32 DB61-02349A CLIP BRUSH NYLON66,BLACK 2 2 SNA
33 DB90-02101A ASS'Y COVER CONTROL ASS'Y 1 1 SA
34 DB93-05959J ASS'Y PCB ASS'Y 1 1 SA
35 DB63-01299C FILTER ASS'Y 1 1 SA
AVXDSH045E✳
AVXDSH056E✳
ND045LHXE✳
ND056LHXE✳
AVXDSH071E✳
ND071LHXE✳
