Exploded Views and Parts List
Samsung Electronics 5-34
■ Parts List
No. SA/SNADescription Specification
Q'TY
Code No.
056 071
1 DB90-03809A ASS'Y CABINET FRONT ASS'Y 1 1 SA
2 DB90-03805B ASS'Y CABINET-TOP ASS'Y 1 1 SA
3 DB90-02928A ASS'Y COVER-PIPE ASS'Y 1 1 SA
4 DB90-03807B ASS'Y CABINET-BOTTOM BLOWER ASS'Y 1 1 SA
5 DB90-03810A ASS'Y CABINET-SIDE RH ASS'Y 1 1 SA
6 DB90-02930A ASS'Y CABINET-SIDE LF ASS'Y 1 1 SA
7 DB90-03813A ASS'Y BRACKET OUTLET PART ASS'Y 1 1 SNA
8 DB91-03808A ASS'Y CABINET BOTTOM DRAIN ASS'Y 1 1 SA
9 DB61-01282A HOLDER-SIDE CABI SGCC-M, T0.8 4 4 SNA
10 DB61-02378A HOLDER PIPE SGCC-M, T1.0 1 1 SNA
11 DB63-01297A COVER-HOLDER SGCC-M, T0.8 1 1 SNA
12 DB63-01657A FILTER-PRE ASS'Y, T4.5, NATURE 1 1 SA
13 DB96-10906A ASS'Y EVAP UNIT AVXDUH071E✳ - 1 SNA
DB96-10906B ASS'Y EVAP UNIT AVXDUH056E✳ 1 - SNA
14 DB93-03364B ASS'Y CONTROL IN ASS'Y 1 1 SNA
14-1 DB90-02981B ASS'Y CASE CONTROL ASS'Y 1 1 SA
14-2 DB61-02287A CASE PCB ABS V0, T2.5 1 1 SA
14-3 DB26-00080A TRANS POWER AC 230V, 50HZ 1 1 SA
14-4 2301-001381 C-FILM, LEAD-OTHER 8000nF, 450V, BK 1 1 SA
14-5 DB65-00105L TERMINAL BLOCK DAF-S6P 1 1 SA
14-6 DB65-00105M TERMINAL BLOCK DAF-S6P 1 1 SA
14-7 DB61-00250A HOLDER-WIRE CLAMP ABS, BLK, ISI, SAMLINE 2 2 SNA
14-8 DB93-05959L ASS'Y PCB MAIN-IN ASS'Y 1 1 SNA
15 DB63-01697A COVER-CONTROL SGCC-M, T0.8 1 1 SA
16 DB94-01697A ASS'Y DRAIN PAN ASS'Y 1 1 SA
17 DB61-03058A BRACKET MOTOR SGCC-M, T2.0 1 1 SA
18 DB31-00514A MOTOR-FAN YSK140-200-4E1 1 1 SNA
19 DB90-04047A ASS'Y CASE BLOWER UPPER ABS, T2.0 2 2 SA
20 DB61-03060A CASE BLOWER BOTTOM ABS, T2.0 2 2 SA
21 DB67-00583A BLOWER-C ABS 2 2 SA
22 DB97-03751A ASS'Y BAND MOTOR ASS'Y 1 1 SNA
23 DB32-00142B THERMISTOR IN 10Kohm, 103AT 1 1 SA
