Exploded Views and Parts List
Samsung Electronics 5-36
■ Parts List
No. SA/SNADescription Specification Q'TYCode No.
1 DB90-03109A ASS'Y CABINET-TOP mA0 PJT, SSEC 1 SNA
2 DB90-03110A ASS'Y CABINET-BOTTOM BLOWER mA1, SSEC 1 SA
3 DB90-02409A ASS'Y CABINET-BOTTOM DRAIN mA1, SSEC 1 SA
4 DB90-02929A ASS'Y CABINET-SIDE RH mA0 PJT, SSEC 1 SA
5 DB61-01282A HOLDER-SIDE CABI ADC6000TG, SGCC-M, T3.0 4 SA
6 DB90-02930A ASS'Y CABINET-SIDE LF mA0 PJT, SSEC 1 SA
7 DB90-02928A ASS'Y COVER-PIPE mA0 PJT, SSEC 1 SA
8 DB91-00346A ASS'Y DRAIN PAN DH42BTA, SSEC 1 SA
9 DB61-02643A BRACKET-FILTER SGCC-M, T0.8 4 SA
10 DB32-00142B THERMISTOR-IN 10Kohm, 103AT 1 SA
11 DB63-01657A COVER-CONTROL mA0 DUCT, SGCC-M, T0.8 1 SA
12 DB63-01657A FILTER-PRE ASS'Y, T4.5, NATURE 1 SA
13 DB96-10905A ASS'Y EVAP UNIT AVXDUH090E* 1 SA
14 DB94-01274A ASS'Y FAN IN PARTS H094EAMC, 220~240V 1 SA
14-1 DB90-02926A ASS'Y CABI FRONT mA0 PJT, SSEC 1 SA
14-2 DB90-03030A ASS'Y-BRACKET OUTLET PART H094EAMC, SSEC 1 SA
14-3 DB61-03058A BRACKET-MOTOR SGCC-M, T2.5 1 SA
14-4 DB97-03751A ASS'Y-BAND MOTOR SLIM DUCT 3, SSEC 1 SA
14-5 DB61-03059A CASE BLOWER-UP ABS+10%GF 2 SA
14-6 DB61-03060A CASE BLOWER-LOW ABS+10%GF 2 SA
14-7 DB67-00583B BLOWER-D EH140EZMC, ABS 2 SA
14-8 DB31-00355B MOTOR-FAN YSK140-200-4 1 SA
15 DB93-03364B ASS'Y CONTROL IN ASS'Y 1 SA
