Exploded Views and Parts List
Samsung Electronics 5-38
■ Parts List
No. SA/SNADescription Specification Q'TYCode No.
1 DB90-03109A ASS'Y CABI BASE ASS'Y,SGCC-M,T1.0 1 SA
2 DB90-02409A ASS'Y CABI BOTTOM DRAIN ASS'Y,SGCC-M,T1.0 1 SA
3 DB90-03110A ASS'Y CABI BOTTOM BLOWER ASS'Y,SGCC-M,T1.0 1 SA
4 DB90-02406A ASS'Y CABI SIDE RH ASS'Y,SGCC-M,T1.0 1 SA
5 DB61-01282A HOLDER SIDE CABI SGCC-M,T3.0 4 SNA
6 DB90-02407A ASS'Y CABI SIDE LF ASS'Y,SGCC-M,T1.0 1 SA
7 DB90-02404A ASS'Y COVER PIPE ASS'Y,SGCC-M,T1.0 1 SA
8 DB91-00346A ASS'Y DRAIN PAN ASS'Y,SGCC-M,T1.0 1 SA
9 DB61-02374A BRACKET FILTER SGCC-M,T1.0 4 SNA
10 DB63-01297A COVER HOLDER SGCC-M,T1.0 1 SNA
11 DB61-02378A HOLDER PIPE SGCC-M,T1.0 1 SNA
12 DB63-01299B FILTER PRE ASS'Y 1 SA
13 DB96-07234A ASS'Y EVAP UNIT 3R14C WAVE 1.3 OD7 1 SA
14 DB94-01691A ASS'Y BLOWER ASS'Y 1 SNA
14-1 DB90-02402A ASS'Y CABI FRONT ASS'Y,SGCC-M,T1.5 1 SNA
14-2 DB90-02408A ASS'Y BRACKET OUTLET PART ASS'Y,SGCC-M,T1.0 1 SA
14-3 DB61-02331A BRACKET MOTOR ASS'Y,SGCC-M,T2.5 1 SNA
14-4 DB72-03751A BAND MOTOR ASS'Y,SGCC-M,T1.6 4 SA
14-5 DB61-02333A CASE FAN LOW ASS'Y,ABS/GF10,T3.0 2 SA
14-6 DB61-02332A CASE FAN UP ASS'Y,ABS/GF10,T3.0 2 SA
14-7 DB67-00583B BLOWER ASS'Y,ABS/GF10,OD230 2 SA
14-8 DB31-00355B MOTOR FAN YSK140-200-4A 1 SA
15 DB93-03364B ASS'Y CONTROL IN ASS'Y 1 SA
15-1 DB90-01992A ASS'Y CASE CONTROL ASS'Y,SGCC-M T1.0 1 SNA
15-2 DB61-02287A CASE PCB ABS V0 1 SA
15-3 DB26-10070G TRANS POWER DC17V 1 SNA
15-4 3502-001027 SSR OMRON G3NA-210BPL 1 SNA
15-5 2301-001381 C-FILM, LEAD-OTHER 8uF,450VAC 1 SA
15-6 DB65-00105M TERMINAL BLOCK 6P 250V,20A 1 SNA
15-7 DB65-00105L TERMINAL BLOCK 6P 250V,20A 1 SNA
15-8 DB61-00250A HOLDER-WIRE CLAMP NYLON 2 SNA
15-9 DB93-05959L ASS'Y PCB MAIN ASS'Y 1 SA
16 DB63-01296A COVER CONTROL ASS'Y,SGCC-M T0.8 1 SA
17 DB32-00142B THERMISTOR -ASS'Y 103AT,103FW 1 SA
