Samsung AVXTJH028EE - Page 269

Exploded Views and Parts List
Samsung Electronics 5-42
■ Parts List
No. SA/SNADescription Specification Q'TYCode No.
1 DB90-02013A ASSY-BRACKET OUTLET PART DH60FTA,SSEC 1 SA
2 DB90-05168C ASSY CABI FRONT NS140HHXEA,SSEC 1 SA
3 DB90-02008A ASSY CABINET-BOTTOM BLOWER DH60FTA,SSEC 1 SA
4 DB95-04518A ASSY MOTOR-BLOWER NS140HHXEA/XSA,SSEC 1 SA
5 DB95-04518B ASSY MOTOR-BLOWER NS140HHXEA/XSA,SSEC 1 SA
6 DB61-01282A HOLDER-SIDE CABI ADC6000TG,SGCC-M,T3.2,45.2,65 4 SA
7 DB90-02010A ASSY CABINET-SIDE LF DH60FTA,SSEC 1 SA
8 DB61-02379A BRACKET EVAP-LF DUCT 60K,SGCC-M,T1.5,65,401,-,SSEC 1 SA
9 DB91-00317A ASSY DRAIN PAN DH60FTA,SSEC 1 SA
10 DB96-07235A ASSY EVAP UNIT ND140HHXEA 1 SA
11 DB90-04066A ASSY BRACKET-EVAP RH DH140EAMC,220-240V,50Hz 1 SA
12 DB90-02009A ASSY CABINET-SIDE RH DH60FTA,SSEC 1 SA
13 DB90-02011A ASSY COVER-PIPE DH60FTA,SSEC 1 SA
14 DB90-02006C ASSY CABINET-TOP HH175EZMC,SSEC 1 SA
14-1 DB61-02374A BRACKET-FILTER DUCT 60K,SGCC-M,T1.0,50,250,-,SSEC 1 SA
14-2 DB64-01371A CABINET-TOP DUCT 60K,SGCC-M,T1.0,710,1240,-,-,SSEC 1 SA
15 DB90-02007B ASSY CABINET-BOTTOM DRAIN HH175EZMC,SSEC 1 SA
15-1 DB61-02374A BRACKET-FILTER DUCT 60K,SGCC-M,T1.0,50,250,-,SSEC 1 SA
15-2 DB64-01367A CABINET-BOTTOM DRAIN DUCT 60K,SGCC-M,T1.0,310.7,1240,-,-,SSEC 1 SA
16 DB93-10768A ASSY CONTROL IN HP,HSP-DUCT 1 SA
16-1 DB90-01992C ASSY CASE-CONTROL NS140HHXEA,SSEC 1 SA
16-2 DB26-00107A TRANS POWER AC 230V,DC 16.7V,DC 0.5A,SSEC 1 SA
16-3 2501-001315 C-OIL 15uF,450V,BK,53x50x65mm,16mm 1 SA
16-4 DB61-02319B CLIP-TERMINAL CAPACITOR HSP DUCT,GI-SGCC,T0.8 1 SA
16-5 DB61-00250A HOLDER-WIRE CLAMP NYLON66,BLK,ISI,SAMLINE,10.3g 2 SA
16-6 DB65-00105L TERMINAL BLOCK
MINI-DVM,PBT,6-TAB_6-SCREW,1.5mm^2,58.4*36.4mm,BLK,B_Type 1 SA
16-7 DB65-00105M TERMINAL BLOCK MINI-DVM,PBT,6-TAB_6-SCREW,1.5mm^2,58.4*36.4mm,BLK,B_Type 1 SA
16-8 DB61-01948A CASE-SUB PCB MH080FXEA4,ABS V0,2,47,65,BLK,FJM-P/J,31.1g 1 SA
16-9 DB93-10766A ASSY PCB SUB-MOTOR_DRIVE HSP-DUCT,N 1 SA
16-10 DB61-02287B CASE PCB EH070CAV,ABS,5V,T2.5 1 SA
16-11 3502-001035 SSR DC 12V,-,10A,1ms,- 1 SA
17 DB63-01296A COVER-CONTROL DUCT 60K,SGCC-M,T0.8 1 SA
18 DB93-10765B ASSY PCB MAIN-IN HSP-DUCT,Y,LINEAR 1 SA
