Samsung AVXTJH028EE - Page 271

Exploded Views and Parts List
Samsung Electronics 5-44
■ Parts List
No. SA/SNADescription Specification
Q'TY
Code No.
AVXDUH210EG AVXDUH280EG
1 DB90-05299A ASS'Y CABINET-TOP SGCC-M,T1.4 1 1 SA
2 DB90-05187A ASS'Y CABINET-SIDE LF SGCC-M,T1.4 1 1 SA
3 DB90-05186A ASS'Y CABINET-SIDE RH SGCC-M,T1.4 1 1 SA
4 DB90-05300A ASS'Y CABINET-FRONT SGCC-M,T1.4 1 1 SA
5 DB90-04652A ASS'Y BRACKET-OUTLET SGCC-M,T1.6 1 1 SA
6 - ASS'Y BLOWER & MOTOR LF ASS'Y 1 1 -
6-1 DB94-02199A ASS'Y BLOWER-HOUSING ASS'Y, SGCC 1 1 SA
6-2 DB94-02200A ASS'Y BLOWER AL5052P 1 1 SA
6-3 DB31-00552E MOTOR-FAN LF OSME-4804SAC - 1 SA
DB31-00552H MOTOR-FAN LF OSME-4804SAC 1 - SA
7 - ASS'Y BLOWER & MOTOR RH ASS'Y 1 1 -
7-1 DB94-02199A ASS'Y BLOWER-HOUSING ASS'Y, SGCC 1 1 SA
7-2 DB94-02200A ASS'Y BLOWER AL5052P 1 1 SA
7-3 DB31-00552F MOTOR-FAN RH OSME-4904SAC - 1 SA
DB31-00552G MOTOR-FAN RH OSME-4904SAC 1 - SA
8 DB96-13201A ASS'Y EVAP UNIT ASS'Y 1 1 SA
8-1 DB96-12781A ASS'Y EVAP-SUB ASS'Y 1 1 SA
8-2 DB96-12776A ASS'Y COLLECTOR OUT ASS'Y 1 1 SNA
8-3 DB96-13034A ASS'Y VALVE EEV ASS'Y 1 1 SNA
8-4 DB96-13197A ASS'Y TUBECAPILLARY ASS'Y 1 1 SNA
9 DB94-02452A ASS'Y DRAIN PAN ASS'Y,SGCC-M,T1.4 1 1 SA
10 DB90-04666A ASS'Y CABINET-BOTTOM DRAIN ASS'Y,SGCC-M,T1.4 1 1 SA
11 DB90-05301A ASS'Y CABINET-BOTTOM BLOWER ASS'Y,SGCC-M,T1.4 1 1 SA
12 DB90-05185A ASS'Y COVER SERVICE ASS'Y,SGCC-M,T1.4 1 1 SA
13 DB93-08781A ASS'Y CONTROL IN ASS'Y,SGCC-M,T0.8 1 1 SA
14 DB90-04778A ASS'Y COVER PIPE RH ASS'Y,SGCC-M,T1.4 1 1 SNA
15 DB61-03910A BRACKET FILTER SGCC-M,T1.4 1 1 SNA
16 DB63-02332A FILTER PRE PVC 1 1 SA
17 DB61-03920A HANGER-SIDE CABI ASS'Y,SGCC-M,T3.0 1 1 SA
18 DB63-02326A COVER-CONTROL ASS'Y,SGCC-M,T0.8 1 1 SNA
