Exploded Views and Parts List
Samsung Electronics 5-46
■ Parts List
No. SA/SNADescription Specification Q'TYCode No.
1 DB90-04677A ASS'Y CASE-CONTROL ASS'Y 1 SA
2 DB93-08764A ASS'Y PCB MAIN ASS'Y 1 SA
3 2501-001315 C-COIL 15uF, 450VAC, AL CAN TYPE 2 SA
4 DB61-03926A CLIP-CAPACITOR T1.4x15xL195.8 2 SA
5 DB61-00250A HOLDER WIRE CLAMP NYLON, BLK 2 SNA
6 DB73-00023B RUBBER COVER WIRE Φ54 4 SNA
7 6009-001001 SCREW-SPECIAL TH, M4, L8, ZPC(WHT), SWRCH18A 3 SNA
8 6002-001149 SCREW-TAPPING TH, 2S, M4, L12, DACRO, SWRCH18A 8 SNA
9 6002-000535 SCREW-TAPPING PH, 2S, M4, L8, ZPC(WHT), STS304 2 SA
10 6002-000548 SCREW-TAPPING TH, 2S, M4, L25, ZPC(WHT), STS304 4 SNA
11 DB91-00309A SCREW-TAPPING PH, M3, L20, ZPC(YEL) 1 SNA
12 DB61-03922A SUPPORT-PCB ABS 4 SNA
13 DB61-04023A SUPPORT-SPACER DONG-A, DASS-13N 1 SA
14 DB65-00182B TERMINAL-BLOCK L, N 1 SNA
15 DB65-00277A TERMINAL-BLOCK F1, F2, V1, V2, F3, F4 1 SA
16 DB71-50031B WIRE HOLDER NY66, DAWH-3ND, IDΦ25 3 SNA
17 DB93-07826A ASS'Y CONNECTOR WIRE POWER ASS'Y 1 SA
18 DB93-08720A ASS'Y CONNECTOR WIRE-COMMUNICATION ASS'Y 1 SNA
19 DB98-30697C ASS'Y LABEL CAUTION ASS'Y 1 SNA
