Samsung AVXTJH028EE - Page 275

Exploded Views and Parts List
Samsung Electronics 5-48
■ Parts List
No. SA/SNADescription Specification
Q'TY
Code No.
ND200HHXE✳ ND220HHXE✳ ND280HHXE✳
1 DB90-06462A ASS'Y CABINET-TOP PART SGCC 1 1 1 SNA
2 DB90-06459A ASS'Y CABINET-BASE DRAIN PART 1 1 1 SNA
2-1 DB64-02756A CABINET-BASE BLOWER SGCC 1 1 1 SNA
2-2 DB64-02757A CABNET-BASE DRAIN SGCC 1 1 1 SNA
3 DB91-01247A ASS'Y DRAIN PAN SECC 1 1 1 SNA
4 DB96-15928A ASS'Y EVAP PARTS 7HP 1 - - SNA
DB96-15610B ASS'Y EVAP PARTS 8HP 1 SNA
DB96-15610A ASS'Y EVAP PARTS 10HP - 1 SNA
4-1 DB96-15734A ASS'Y EVAP UNIT 7HP 1 - - SA
DB96-15733B ASS'Y EVAP UNIT 8HP 1 SA
DB96-15733A ASS'Y EVAP UNIT 10HP - 1 SA
4-2 DB61-04979A BRACKET EVAP-LF SECC 1 1 1 SNA
4-3 DB61-04981A BRACKET EVAP-RH SECC 1 1 1 SNA
4-4 DB95-01958D ASS'Y THEMISTOR- EVA OUT 1 1 1 SA
4-5 DB95-04530A ASST THEMISTOR-ROOM EVA IN 1 1 1 SA
5 DB90-06460A ASS'Y CABINET-SIDE RH PART 1 1 1 SNA
5-1 DB90-06419A ASS'Y CABINET-SIDE RH SGCC 1 1 1 SNA
5-2 DB63-03007A COVER-PIPE SGCC 1 1 1 SNA
5-3 DB61-04984A BRACKET CONTROL-BASE SGCC 1 1 1 SNA
6 DB93-11723B ASS'Y CONTROL IN 1 1 1 SNA
6-1 DB90-06715A ASS'Y CASE-CONTROL SGCC 1 1 1 SNA
6-2 DB63-03004A COVER-CONTROL SGCC 1 1 1 SNA
6-3 DB26-00095A TRANS POWER 1 1 1 SA
6-4 DB27-00093A COIL CHOKE-REACTOR 1 1 1 SA
6-5 DB61-00250A HOLDER WIRE 2 2 2 SNA
6-6 DB93-12654A ASS'Y PCB MAIN IN 1 1 1 SA
6-7 DB93-12108A ASS'Y PCB SUB EMI 1 1 1 SA
6-8 DB93-12676A ASS'Y-BLDC DRIVER 1 1 1 SA
6-9 DB65-00179F TERMINAL BLOCK 1 1 1 SA
6-10 DB65-00179E TERMINAL BLOCK 1 1 1 SA
7 DB90-06422A BRACKET INLET SECC 1 1 1 SNA
8 DB90-06422A BRACKET INLET SECC 1 1 1 SNA
9 DB90-06461A ASS'Y CABINET-SIDE LF PART SGCC 1 1 1 SNA
10 DB61-04882A BRACKET HINGE-SIDE CABI SGCC 4 4 4 SNA
11 DB94-03142A ASS'Y FAN IN PARTS 1 1 1 SNA
11-1 DB67-01123A DUCT-BACK HIPS 2 2 2 SNA
11-2 DB94-03168A ASS'Y FAN-BLOWER ABS+GF10 2 2 2 SNA
11-3 DB31-00593B MOTOR FAN 1 1 1 SA
11-4 DB61-04881A BASE MOTOR SGCC 1 1 1 SNA
11-5 DB67-01124A DUCT-OUT OFF HIPS 2 2 2 SNA
11-6 DB67-01122A DUCT-FRONT HIPS 2 2 2 SNA
12 DB90-06417A ASS'Y CABI FRONT PANEL SGCC 1 1 1 SNA
