Exploded Views and Parts List
Samsung Electronics 5-60
■ Parts List
No. SA/SNADescription Specification Q'TYCode No.
1 DB94-00454H ASS'Y BACK BODY ASS'Y 1 SA
1-1 DB61-01632D BACK BODY HIPS 1 SNA
1-2 DB69-00834A CROSS FAN EPS 1 SNA
1-3 DB96-03149A ASS'Y SUPPORT EVAP RH HIPS 1 SA
1-4 DB31-00219A MOTOR IN 220-240V~,50/60Hz,Class E 1 SA
1-5 DB94-00456A ASS'Y CROSS FAN OD92xL635 1 SA
1-6 DB97-02075A ASS'Y BOLT SPECIAL ASS'Y 1 SNA
1-7 DB94-00455A ASS'Y RUBBER BEARING ASS'Y 1 SNA
1-8 DB94-40007A ASS' Y BEARING BEARING 1 SA
1-9 DB69-00833A CUSHION EVAP UP EPS - SA
2 DB96-09930A ASS'Y EVAP TOTAL ASS'Y 1 SA
2-1 DB63-00850A COVER BEARING ABS - SNA
2-2 DB96-03060G ASS'Y EVAP ASS'Y 1 SNA
3 DB94-00457J ASS'Y TRAY DRAIN ASS'Y 1 SA
3-1 DB63-00848A TRAIN DRAIN ABS 1 SNA
3-2 DB61-01635C BRADE-H HIPS 1 SA
3-3 DB61-01636A BLADE-V PP 1 SA
3-4 DB63-00849A TRAY STABILIZER ABS 1 SNA
3-5 DB69-00839A CUSHION EPS TRAY RH EPS 3 SA
3-6 DB73-00180A RUBBER CAP DRAIN GUM-EPM 3 SNA
3-7 DB31-00371A ASS'Y MOTOR STEPPING 220-240V~,50/60Hz,Class E 1 SA
3-8 DB94-00458B ASS'Y DRAIN HOSE ASS'Y 1 SA
4 DB93-06025C ASS'Y CONTROL IN ASS'Y 1 SA
5 DB92-01237A ASS'Y PANEL FRONT ASS'Y 1 SA
5-1 DB64-00989E PANEL FRONT HIPS 1 SA
5-2 DB92-01207A ASS'Y GRILLE AIR INLET ASS'Y 1 SA
5-3 DB90-03094A ASS'Y COVER DISPLAY ASS'Y 1 SA
5-4 DB63-01591A GUARD AIR FILTER PP 1 SNA
6 DB97-02851B ASS'Y PLATE HANGER ASS'Y - SNA
7 DB61-01638B HOLDER PIPE PS 1 SNA
8 DB90-03965A ASS'Y COVER TERMINAL ASS'Y 1 SA
9 DB93-03170Z ASS'Y REMOCON ARH-463 1 SA
