Exploded Views and Parts List
Samsung Electronics 5-62
■ Parts List
No.
SA/SNA
Description Specification
Q'TY
Code No.
AVXWNH056E✳
ND056NH✳✳✳
1 DB94-00615B ASS'Y BACK BODY ASS'Y 1 1 SA
1-1 DB61-01974B BACK BODY HIPS 1 1 SNA
1-2 DB69-01039A CUSHION BACK BADY EPS 1 1 SNA
2 DB96-06587D ASS'Y EVAP TOTAL ASS'Y 1 SA
DB96-09941A ASS'Y EVAP TOTAL ASS'Y 1 SA
2-1 DB63-01065A COVER BEARING ABS 1 1 SNA
2-2 DB96-07606A ASS'Y EVAP MAIN ASS'Y 1 1 SNA
DB96-06525B ASS'Y EVAP SUB ASS'Y 1 1 SNA
2-3 DB96-07590A ASS'Y TUBE EVAP OUT ASS'Y 1 1 SA
2-4 DB96-07589A ASS'Y TUBE EVAP IN ASS'Y 1 SA
DB96-09934A ASS'Y TUBE EVAP IN ASS'Y 1 SA
2-5 DB60-00192A SPACE EVAP LOW 1 1 SNA
3 DB94-00616E ASS'Y TRAY DRAIN ASS'Y 1 1 SA
3-1 DB63-01071A TRAIN DRAIN ABS 1 1 SNA
3-2 DB61-01975C BRADE-H HIPS 1 1 SA
3-3 DB61-01976A BLADE-V PP 1 1 SA
3-4 DB63-01066A TRAY STABILIZER ABS 1 1 SNA
3-5 DB69-01024A CUSHION EPS TRAY RH EPS 1 1 SA
3-6 DB73-00180A RUBBER CAP DRAIN GUM-EPM 1 1 SNA
3-7 DB31-00285A ASS'Y MOTOR STEPPING 220-240V~,50/60Hz,Class E 1 1 SA
3-8 DB94-00458B ASS'Y DRAIN HOSE ASS'Y 1 1 SA
4 DB93-06038C ASS'Y CONTROL IN ASS'Y 1 1 SA
5 DB92-01235A ASS'Y PANEL FRONT ASS'Y 1 1 SA
5-1 DB64-01184C PANEL FRONT HIPS 1 1 SA
5-2 DB64-02045A ASS'Y GRILLE AIR INLET ASS'Y 1 1 SA
5-3 DB64-02046A DECORATON GRILLE PC(GRAY) 1 ` SA
5-4 DB93-02867C ASS'Y COVER DISPLAY ASS'Y 1 1 SA
5-5 DB63-01592B GUARD AIR FILTER PP 2 2 SNA
6 DB90-02738A ASS'Y PLATE HANGER ASS'Y 1 1 SNA
7 DB61-01981B HOLDER PIPE PS 1 1 SNA
8 DB90-03966A ASS'Y COVER TERMINAL ASS'Y 1 1 SA
9 DB93-03170Z ASS'Y REMOCON ARH-463 1 1 SA
10 DB96-03817A ASS'Y SUPPORT EVAP RH HIPS 1 1 SA
11 DB31-00267A MOTOR IN 220-240V~,50/60Hz,Class E 1 1 SA
12 DB94-00456B ASS'Y CROSS FAN OD92xL635 1 1 SA
13 DB97-02075A ASS'Y BOLT SPECIAL ASS'Y 1 1 SNA
14 DB94-00455A ASS'Y RUBBER BEARING ASS'Y 1 1 SNA
15 DB94-40007A ASS'Y BEARING MOTOR BEARING 1 1 SA
16 DB61-01977A BRACKET EVAP SGCC-M 1 1 SA
AVXWNH071E✳
ND071NH✳✳✳
