Product Specifications
2-20 Samsung Electronics
Model
AVXDUH056E6
ND056SH666
AVXDUH071E6
ND071SH666
AVXDUH090E6
ND090SH666
AVXDUH112E6
ND112SH666
AVXDUH128E6
ND128SH666
AVXDUH140E6
ND140SH666
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 5.6 7.1 9 11.2 12.8 14
Btu/h 19,100 24,200 30,700 38,200 43,600 47,700
Heating*
3)
kW 6.3 8.0 10.0 12.5 13.8 16.0
Btu/h 21,400 27,200 34,100 42,600 47,000 54,500
Condensate (with High fan speed) Liters/h 4.63 4.95 5.1
Power
Input W 130
*5)
190
*5)
240
*5)
260 370 410
Running Current A 1.10
*5)
1.25
*5)
1.30
*5)
1.17 1.67 1.86
Sound Level Sound Pressure (High/Low)*
4)
dB(A) 37 / 33 39 / 35 39 / 35 39 / 35 39 / 35 43 / 38
Fan
Type - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model -
YSK110-50-4SM YSK140-60-4B YSK140-200-4 YSK140-200-4 YDK-370S43223-01 YDK-370S43223-01
Type - Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Output W ------
Airflow Rate
Cooling (High) m
3
/min 14.5 18.5 19.5 27.0 32.0 37.0
Heating (High) m
3
/min 15.5 20.0 21.5 27.0 31.0 36.0
External Static Pressure Standard(Min.~Max) mmH2O 4(0~6) 4(0~6) 6(4~8) 8 (6~10) 8 (6~10) 8 (6~10)
Refrigerant
Type - R410A R410A R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV EEV EEV
Temperature Control -
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 9.52 9.52 9.52 9.52 9.52
Gas (Flare) ø, mm 12.7 15.88 15.88 15.88 15.88 15.88
Drain ø, mm
VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight
Net Weight kg 31 31 35 39.0 52.0 52.0
Shipping Weight kg 36 36 41 46.0 60.0 60.0
Dimensions
Net Dimensions (W x H x D) mm 900x260x480 900x260x480 1,150x260x480 1,150x320x480 1,200x360x650 1,200x360x650
Shipping Dimensions (W x H x D) mm 1,146x363x584 1,146x363x584 1,390x345x574 1,396x424x584 1,447x425x769 1,447x425x769
Functions
Auto Restart - OOOOOO
Auto Swing - XXXXXX
Group/Individual Control - OOOOOO
External Contact Control - OOOOOO
Trouble Shooting by LED - XXXXXX
Standard
Accessories
Installation Manual - OOOOOO
Operation Manual - OOOOOO
Pattern Sheet for Installation - XXXXXX
Flexible Drain Hose - OOOOOO
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Optional
Accessories
Wireless Remote Controller - MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
Duct Receiver Kits
Receiver
- MRK-A01 MRK-A01 MRK-A01 MRK-A01 MRK-A01 MRK-A01
Receiver Wire
- MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
Wired Remote
Controller
Simplified - MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00
Standard - MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01
Premium - MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
Drain Pump
MDP-M075SGU3 MDP-M075SGU1 MDP-M075SGU1 MDP-M075SGU1 MDP-M075SGU2 MDP-M075SGU2
Indoor Unit(cont.)
QMSP duct
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
