Exploded Views and Parts List
Samsung Electronics 5-110
■ Parts List(cont.)
Q'TY
RD140HRXGB
RD140HRXGASTK
Code No.No. SA/SNADescription Specification
41 DB96-14630A ASS'Y TUBE SUBCOOLER HR 16HP ASS'Y 1 SA
42 DB96-14634A ASS'Y TUBE EXPANSION VALVE HR 14HP ASS'Y 1 SA
43 DB96-14262A ASS'Y ACCUMULATOR 20HP ASS'Y 1 SA
44 DB96-14641A ASS'Y TUBE LIQUID BYPASS VALVE HR 14HP ASS'Y 1 SA
45 DB96-14252A ASS'Y TUBE OIL GAS VALVE20HP ASS'Y 1 SA
46 DB96-14529A ASS'Y TUBE SUCTION PWM VALVE 14HP ASS'Y 1 SA
47 DB96-14579A ASS'Y TUBE OIL RETURN 14HP ASS'Y 1 SA
48 DB96-14229A ASS'Y TUBE OIL SEPA OUT 14HP ASS'Y 1 SA
49 DB96-14222A ASS'Y TUBE VAPOR INJECTION 14HP ASS'Y 1 SA
50 DB96-14249A ASS'Y TUBE OIL BALANCE VALVE 14HP ASS'Y 1 SA
51 DB96-15593A ASS'Y TUBE DISCHARGE EU 14HP ASS'Y 1 SA
52 DB96-15367A ASS'Y FELT OIL SEPARATOR 14HP ASS'Y 1 SA
53 DB96-15594A ASS'Y TUBE EVI BYPASS EU 14HP ASS'Y 1 SA
54 DB96-14245A ASS'Y TUBE HOT GAS VALVE 20HP ASS'Y 1 SA
55 DB95-01468E ASS'Y COMP EVI ZPJ83KCE-TFD-496 1 SA
56 DB95-01456E ASS'Y COMP EVI ZPI83KCE-TFD-496 1 SA
57 DB97-15950A ASS'Y CLOTH COMP SOUND SIDE COMP FELT, 1st 1 SA
58 DB97-15951A ASS'Y CLOTH COMP SOUND SIDE COMP FELT, 2nd 1 SA
59 DB63-02031A COVER COMP SOUND TOP COMP COVER, 1st 1 SA
60 DB63-02032A COVER COMP SOUND TOP COMP COVER, 2nd 1 SA
61 DB95-00766P ASS'Y COMP HEATER ASS'Y 1 SA
62 DB95-00766Q ASS'Y COMP HEATER ASS'Y 1 SA
64 DB95-04694A ASS'Y THEMISTOR 2COMP TOTAL ASS'Y 1 SA
65 DB95-04537D ASS'Y THEMISTOR SUMP1 EVI EVO SUMP1 EVI EVO 1 SA
66 DB95-04538D ASS'Y THEMISTOR SUMP2 DIS2 SUC LIQ SUMP2 DIS2 SUC LIQ 1 SA
67 DB95-04539D ASS'Y THEMISTOR DIS1 OIL CONOUT DIS1 OIL CONOUT 1 SA
68 DB93-10867C ASS'Y CONNECTOR WIRE COMP TOTAL ASS'Y 1 SA
69 DB93-10834A ASS'Y CONNECTOR WIRE COMP COMP 1st 1 SA
70 DB93-10834B ASS'Y CONNECTOR WIRE COMP COMP 2nd 1 SA
71 DB90-06138A ASS'Y CABINET POWER BOX ASS'Y 1 SA
72 DB65-00232C TERMINAL BLOCK 3PHASE 3PHASE 1 SA
73 DB90-03795A ASS'Y SUPPORT WIRE ASS'Y 1 SA
74 DB61-03441A SUPPORT WIRE BODY ABS, 5VA 1 SA
75 DB61-03442A SUPPORT WIRE COVER ABS, 5VA 1 SA
76 DB90-05866A ASS'Y COVER POWER BOX ASS'Y 1 SA
77 DB65-00179D TERMINAL BLOCK COMM 1 SA
78 DB61-04526A CASE TERMINAL ABS, 5VA 1 SA
79 DB93-12483A ASS'Y PCB SUB-EEPROM ASS'Y 1 SA
