PCB Diagram and Parts List
Samsung Electronics 6-40
①
#1:
Input Operating Capacitor Motor
#2 #4: Not Used
#3: Motor Control Signal
#5: N Phase Voltage
②
#1: L Phase
#2: N Phase
③
#1: MPI-
#2: MPI+
#3: 12
#4: MPI Feedback
④
#1: DC12V
#2,3,4: Louver Sontrol Signal
⑤
#1: DC5V
#2: GND
#3: Hall IC Input
⑥
#1: Room Temp. Sensor
#2: GND
#3: EVA IN Temp. sensor
#4: GND
⑦
#1: EVA Out Thermistor
#2: GND
⑧
#1: Comm. Signal F1
#2: Comm. Signal F2
⑨
#1: Comm. Signal F3
#2: Comm. Signal F4
⑩
#1: 12V
#2: GND
⑪
#1~10,#20: Option Switch Address
Signal
#11~14: GND
#15: External Control Signal
#16: Comp Check Signal
#17,#19: 12V
#18: Error Check Signal
⑫
#1: Not Used
#2~12: Display Control
#13: Operating Switch
#14: 5V
#15: Remocon Receiver Signal
#16: GND
⑬
⑭
#1~4: EEV Control Signal
#5: 12V
⑮
#1: 12V
#2~#5: Auto Grille Control
CN73-Fan Motor CN71-AC Power
CN82- MPI
CN60-Up/Down Louver
CN33- Wired Remocon Comm. CN32- Wired Remocon Power
CN61- Option Setup Sub Board
Connection
CN52- RPM Feedback CN41- Temp. Sensor
CN42- Temp. Sensor
CN31- Indoor/Outdoor Unit
Communication
CN91-Display
CN10-Micom Download
CN62-EEV(Not Used)
CN93-Display
Wall-mounted type(Vivace)(cont.)
