ASS'Y PCB MAIN HUB (cont.)
■ DC (cont.)
⑱
#2: Signal
#3: GND
#4: VCC
⑲
#1: Signal
#3: GND
#4: VCC
⑳
#1: COMP3 DISCHARE
#2: COMP3 DISCHARE
#3: COMP3 SUMP
#4: COMP3 SUMP
㉑
#1: 12V
#3: Comm(TX)
#4: Comm(RX)
#5: High Pressure Sensor
#6: Low Pressure Sensor
#7: ZERO CROSSING
#8: PWM Control
#9: VCC
#10: GND
㉒
#1: COMP1 DISCHARGE Temp.
#2: COMP1 DISCHARGE Temp.
#3: Oil Sensor Temp.
#4: Oil Sensor Temp.
#5: COND OUT Temp.
#6: COND OUT Temp.
#7: Air Temp.
#8: Air Temp.
㉓
#1: Signal 1
#2: Signal 2
#3: Signal 3
#4: Signal 4
#5: 12V
㉔
#1: COMP2 SUMP
#2: COMP2 SUMP
#3: COMP2 DISCHARGE
#4: COMP2 DISCHARGE
#5: SUCTION1
#6: SUCTION1
#7: LIQUID
#8: LIQUID
㉕
#1: COMP1 SUMP
#2: COMP1 SUMP
#3: EVI IN
#4: EVI IN
#5: EVI OUT
#6: EVI OUT
#7: SUCTION2
#8: SUCTION2
㉖
#1: Signal 1
#2: Signal 2
#3: Signal 3
#4: Signal 4
#5: 12V
㉗
#1: Signal 1
#2: Signal 2
#3: Signal 3
#4: Signal 4
#5: 12V
㉘
#1: Signal 1
#2: Signal 2
#3: Signal 3
#4: Signal 4
#5: 12V
㉙
##1: Signal 1
#2: Signal 2
#3: Signal 3
#4: Signal 4
#5: 12V
㉚
#1: VCC
#2: MODE
#3: RESET
#4: Signal 1
#5: Signal 2
#6: Signal 3
#7: GND
㉛
#1: Comm (RX)
#2: Comm (TX)
#4: Signal 1
#5: Signal 2
#6: Signal 3
#7: Signal 4
#9: GND
#10: VCC
㉜
#1: F1
#2: F2
CN41 – Low Pressure Sensor CN42 – High Pressure Sensor CN46 – Temp. Sensor CN96 - HUB TO MAIN
CN43 – Temp. Sensor CN64 - EVI-EEV CN44 – Temp. Sensor CN45 – Temp. Sensor
CN63 - MAIN EEV2
CN63 - MAIN EEV1 CN66 - INV-EEV CN65 - HR-EEV
CN95 - DOWNLOAD CN10 - DOWNLOAD(AS-PRO) CN60 - COMM
