Samsung AVXTJH028EE - Disassembly and Reassembly

3-1 Samsung Electronics
QNecessary Tools
3. Disassembly and Reassembly
Item Remark
+Screw Driver
Monkey Spanner
–Screw Driver
Nipper
Electric Motion Driver
L-Wrench
OFor “disassembly and assembly” DVM PLUS Ⅲ/Ⅳ indoor unit, please refer to the products with the same structures. Only those prod-
ucts that are not specified elsewhere are described here.
OReference product groups for DVM PLUS Ⅲ/Ⅳ indoor unit
Classification DVM PLUS III Indoor Unit Model Basic Model
Slim 1 way cassette AVXCSH666Series/ND66616666 Series AIXCSH666
2 way cassette AVXC2H666Series AVXC2H071EA
4 way cassette AVXC4H666Series/ND6664H666 Series AIXC4H666
mini 4 way cassette AVXCMH666Series AVXCMH666EA
SLIM DUCT AVXDSH666Series/ND666L6 Series EH666EAV/EH666EZMC
MSP DUCT AVXDUH666Series/ND666SH666 Series DH666EAMC
HSP DUCT ND666H6 Series AVXDUH666
SUPER DUCT AVXDUH666 Series DC666GTSA
CEILING AVXTFH666Series/ND666CH666 Series FH666EAMC
Console AVXTJH666Series/ND666JH666 Series JH666EAV1
RAC(Montblanc) AVXWBH666Series/ND666BH666 Series MH666FBEA
RAC(Neo-Forte without EEV) AVXWNH666Series/ND666NH666 Series MH666FNEA
RAC(Neo-Forte with EEV) ND666QHX66Series AVXWNH666EE
RAC(Vivace) AVXWVH666Series/ND
666VH666 Series MH666FVEA
