Disassembly and Reassembly
3-3 Samsung Electronics
No Parts Procedure Remark
6) Press the left and right Hooks to
separate the Panel from the Indoor Unit.
Panel & Filter
(B type)
1) Press [Filter Reset] Button on the wire-
less remote controller once. Inlet Panel
will descend as in the picture on the
right.
2) Rotate 2 levers that connect the both
ends of the Inlet Panel and gear as in
the picture on the right.
3) Pull the Inlet Panel to the front to
remove.
$9;&6+B$BaLQGG
To Next Page
