SETTING
Option No. : 02XXXX-1XXXXX-2XXXXX-3XXXXX
Option SEG1 SEG2 SEG3 SEG4 (*1) SEG5 SEG6
Description Page Mode - Fan control when Thermo Off Use of central control -
Display/detail
Display Detail Display Detail Display Detail
Display
Detail
Display Detail
Display Detail
Fan stop
when
Cool/Heat
Thermo
Off
Minimal
fan
operation
when Heat
Thermo
Off
Minimal
fan
operation
when Cool
Thermo
Off
02 -
0
Disuse Disuse Disuse 0 Disuse
-
1
Enable - -
1 Enable
2
Disuse Enable Disuse
3 Enable - -
4 Disuse Disuse Enable
5 Enable - -
6 Disuse Enable Enable
7 Enable - -
Option SEG7 SEG8 SEG9 SEG10 SEG11 (*2) SEG12
Description Page
Set to Enable BLDC Fan and
Modulating Valve
Set BLDC Fan Speed to High Set BLDC Fan Speed to Mid
Set BLDC Fan Speed
to Low
-
Display/detail
Display Detail Display
Detail
Display
Signal voltage
= 7.5 +
α
Display
Signal voltage = 5.0 +
β
Display
Signal
voltage =
2.5 +
γ
Display
Detail
BLDC Fan
Modulating
Valve
α
(V)
β
(V)
γ
(V)
0 Disuse Disuse 0 0 0 0 0 0
-
1 Use Disuse 1 0.3 1 0.3 1 0.3
2 Disuse Use 2 0.7 2 0.7 2 0.7
1 3 Use Use
313 1 31
4 1.4 4 1.4 4 1.4
5 1.7 5 1.7 5 1.7
6 2.1 6 2.1 6 2.1
7 2.5 7 2.5 7 2.5
8 -0.3 8 -0.3 8 -0.3
9 -0.7 9 -0.7 9 -0.7
A-1A -1 A-1
B -1.4 B -1.4 B -1.4
C -1.7 C -1.7 C -1.7
D -2.1 D -2.1 D -2.1
E -2.5 E -2.5 E -2.4
