Samsung DVM - 05 series installation option

39
SETTING
(*4)
• [Cool mode]
– Err= Indoor temperature – Set temperature
– If Err > C+2, the modulating valve operates at the maximum voltage dened with SEG16,
the 02 series installation option. In other cases, the valve step is adjusted in accordance with
the formula given above.
• [Heat mode]
– Err= Set temperature – Indoor temperature + f
❋
f = Heating compensation (correction) temperature (default : 2)
– If Err > C+2, the modulating valve operates at the maximum voltage dened with SEG16,
the 02 series installation option. In other cases, the valve step is adjusted in accordance with
the formula given above.
(*5)
– Cycle: 1 minute
– ΔErr = Err
n
– Err
n-1
– ΔV = D * ΔErr + E * Err
n
– New DCV output = Current DCV output + ΔV
05 series installation option
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0 5
Use Auto Change
Over for 4-pipe only
(When setting SEG3)
Standard heating
temp. offset
(When setting SEG3)
Standard cooling
temp. offset
(When setting SEG3)
Standard for mode
change Heating
→
Cooling
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1
(When setting SEG3)
Standard for mode
change Cooling
→
Heating
(When setting SEG3)
Required time for
mode change
---
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
2
FCU KIT pipe
installation structure
-
Valve open control
when Thermo Off
-
FCU cool air
prevention
compensation
temperature
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
3 ---
Setting cool/heat air
prevention skip
FCU KIT external
room sensor
