Samsung DVM - Option No.: 05 XXXX-1 XXXXX-2 XXXXX-3 XXXXX

41
SETTING
Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
Description Page
FCU KIT pipe installation
structure
-
Valve open control when
Thermo Off
-
FCU cool air prevention
compensation temperature
Display/
detail
Display Detail Display Detail Display Detail Display Detail Display Detail Display Detail
2
0 2-pipe
-
0
Valve close
(normally close
type)
-
0 0°C (0 °F)
1 4-pipe 1
Valve open
(normally close
type)
1 1°C (1,8 °F)
2 2°C (3,6 °F)
3 3°C (5,4 °F)
4 4°C (7,2 °F)
5 5°C (9,0 °F)
6 6°C (10,8 °F)
7 7°C (12,6 °F)
8 -7°C (-12,6 °F)
9 -6°C (-10,8 °F)
A -5°C (-9,0 °F)
B -4°C (-7,2 °F)
C -3°C (-5,4 °F)
D -2°C (-3,6 °F)
E -1°C (-1,8 °F)
F 0°C (0 °F)
Option SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
Description Page - - -
Setting cool/warm air
prevention skip
FCU KIT external room sensor
Display/
detail
Display Detail Display Detail Display Detail Display Detail Display Detail Display Detail
3---
0
Use in cool
Use in heat
0 Disuse
1
Disuse in cool
Use in heat
1 Enable2
Use in cool
Disuse in heat
3
Disuse in cool
Disuse in heat

y
Valve open control when Thermo Off: Set to open valve when Thermo Off in case of
applying Close type water valve (Valve closes normally if it is not set.)

y
FCU cool air prevention compensation temperature: Temperature for preventing cool air
can be controlled.
– Default temp. + SEG18 ≥Water-IN temp. (°C): Heating fan On
– Default temp. + SEG18 < Water-IN temp. (°C): Heating fan Off

y
Fan speed can be various according to the water in temperature.
