1-6. Electric Parts Specification
1. Product Information
Items Specification
Models RS275 RS277
Model 115V 60HZ
Defrost Heater(FRE) Conducting at F Defrosting AC 120V,250W
Defrost Heater(REF) Conducting at R Defrosting AC 120V,140W
DISPENSER Heater Interlock with F-FAN AC 115V, 5W
WATER PIPE Heater - AC 115V,5W
WATER TANK- Heater - AC 115V,4W
Damper Heater DC12V, 1W
Thermal Fuse for preventing
Overheating of Refrigerator Defrost-Heater
AC 250V 10A 77±5℃
Condenser for
COMP (Package type)
Running 12μF,250V
Starting -
Starting-Relay
Model PTHTM100MD3
Operation 10Ω±20%
Over load Relay
Model 4TM435RFBYY-53
Temp. ON 130 ± 5℃
Temp. OFF 61 ± 9℃
Electric Components
