36
The door handles allow access into the refrigerator
and freezer.
They are front mounted with screws.
Lift the handle upward motion with on.
DOOR HANDLE
The door gasket is a molded gasket set into a
channel located in the door liner.
1.Open the door
2.Grasp the gasket and pull in an outward motion
until the molded gasket separates from the door
liner.
DOOR GASKET
3. Disconnect the wire connector in the direction
of the arrow.
1. Remove the screw under the cover
2. Insert a hand on the slot as shown,and unlock
the tabs.
CONTROL PANEL
RemarksWork orderPart name
3. Full disassembly and assembly
If you want to reassemble, follow the reverse order
Be careful of injury
