37
Part name Work order Remarks
DOOR LIGHT
SWITCH
The refrigerator has a door light switch located
in the upper right corner for the refrigerator.
1. Use a small flat blade screwdriver to unlock
the locking tab and pull the switch out until
the wire connector is visible.
TEMPERED GLASS
SHELF
This shelves allow the storage of larger items
and pull out for easy access.
1. Pull the shelf out as far as it goes.
2. Lift it up and remove it.
DRAWER IN
REFRIGERATOR
The door gasket is a molded gasket set into a
channel located in the door liner.
1. Open the door
2. Grasp the gasket and pull in an outward
motion until the molded gasket separates
from the door liner.
GALLON DOOR BIN
The door bins allow storage of perishable items.
1. Push the bin up and slide it out.
3. Full disassembly and assembly
If you want to reassemble, follow the reverse order
Be careful not to scratch
