Samsung Samsung-T Protocol - Swing Operation; Sequence and Tour Commands

Ver
VerVer
Ver 1
11
1.
..
.8
88
80
00
0E
EE
E
- 7 -
2.5
Swing
2.5.1
Set Swing Speed
&
Time
Cmd1 Cmd2 Data1 Data2 Data3 Data4
Send
00h 13h
P1 P2 P3h
00h
Return
" " " " "
Error
P1:
00
h=Pan Swing
01
h=Tilt Swing
02
h=Pan/Tilt Swing
P2:
00h ~ 40h
Swing Speed
P3:
00h ~ 7
Fh Swing Dwell Time(0
~ 127
sec)
2.5.2
Set Swing
Cmd1 Cmd2 Data1 Data2 Data3 Data4
Send
00h 19h
P1 P2 P3h
00h
Return
" " " " "
Error
P1:
00=
Pan Swing
01
h=Tilt Swing
02
h=Pan/Tilt Swing
P2:
00h ~
FEh
=
First preset position
P3:
00h ~
FEh
=
Second preset position
2.5.3
Run Swing
Cmd1 Cmd2 Data1 Data2 Data3 Data4
Send
00h 1
Bh P1
00h 00h 00h
Return
" " " " "
Error
P1:
00
h=Pan Swing
01
h=Tilt Swing
02
h=Pan/Tilt Swing
2.6
Sequence Command
2.6.1
Run Group
Cmd1 Cmd2 Data1 Data2 Data3 Data4
Send
00h 21h
P1
00h 00h 00h
Return
" " " " "
Error
P1:
00h ~ 05h
Group number
2.6.2
Run Tour
Cmd1 Cmd2 Data1 Data2 Data3 Data4
Send
00h 25h 00h 00h 00h 00h
Return
" " " " "
Error
2.6.3
Clear Tour
&
Group
Cmd1 Cmd2 Data1 Data2 Data3 Data4
Send
00h 2
Bh P1 P2
00h 00h
Return
" " " " "
Error
P1:
00
h=Clear the data for Tour
01
h=Clear the data for Group
P2: When P1 is
00
h;
00
h=Tour number F1h=Clear all Tour
When P1 is
01
h;
00
h~05h=Group number F1h=Clear all Group
