SAMWONTECH
4st Edition of TEMI2000_Series IM : Aug. 18. 2009 Page 10 / 55
▶ Target Set Point of humidity for FIX operation can be set through below.
▶ Press the blue button on the left lowerhand corner to pop up numeric Input Keypad [Figure 3-4].
▶ Press the
(RUN) button at the lower right corner to start operation, after complete to input Set
Point for temperature and humidity.
Table 3-1. Temperature, Humidity SP Parameters
Parameter Range Unit Default
Temperature SP T.EU(0.00 ~ 100.00%) T.EU T.EU(0.00%)
Humidity SP H.EU(0.0 ~ 100.0%) H.EU H.EU(0.0%)
※ T.EU : Range of Temperature Sensor
※ H.EU : Range of Humidity Sensor
☞ Refer to [Engineering Units]
[Figure 3-4] Input Keypad for humidity Set Point
