5.4.3 Description of TIME SIGNAL operation
Setting TIME SIGNAL Operation
1. DELAY TIME
= 000.00.00
TIME SIGNAL 2
N SEG TIME≥
DELAY TIME
+OPER.TIME
2. DELAY TIME
≠ 000.00.00
TIME SIGNAL 3
3. DELAY TIME
= 000.00.00
TIME SIGNAL 4
N SEG TIME<
DELAY TIME
+OPER.TIME
☞ Does not
affect the next
segment.
4. DELAY TIME
≠ 000.00.00
TIME SIGNAL 5
(N-1) SEG TIME
N SEG TIME
(N+1) SEG TIME
SEGMENT
OPER.TIME
ON
OFF
TS3
(N-1) SEG TIME N SEG TIME
(N+1) SEG TIME
SEGMENT
OPER.TIME
ON
OFF
TS4
OPER.TIME
ON
OFF
(N-1) SEG TIME
N SEG TIME
(N+1) SEG TIME
TS1
SEGMENT
(N-1) SEG TIME
N SEG TIME
(N+1) SEG TIME
SEGMENT
OPER.TIME
ON
OFF
TS2
DELAY TIME
DELAY TIME
