OPTICAL TUNABLE FILTER OTF-930
5-5
5.2. Rear Panel
(1) Mains Connector Socket
(2) Fuse box
Pull out the fuse box, and replace with new fuses.
(1) (2) (5) (4)
(3)
(3) Serial Number Label
Indicates model number, serial number and options installed on each unit.
(4) GPIB Connector
(5) Slit
Slit for heat dissipation. It is important to leave at least 5 cm of space behind the OTF-930
unit to ensure proper ventilation and cooling.
