Optical Tunable Filter OTF-930
2-1
2
Specications
A wide range of lter types are available. The above table shows an example specication using a
nominal 1.2nm bandwidth (12 type), single cavity, double cascade lter. Please see the serial number
label on the rear panel for details of the lter type and options installed.
The following items should be supplied with your OTF-930 unit:
1. 2 power switch keys
2. Power supply cable
3. Operation Manual
4. Test report
Min. Typ. Max.
Filter Type -
Wavelength Range nm 1530 1610
Insertion Loss dB 2.0 2.5
Bandwidth at -3dB nm 0.8 0.9 1.0
Bandwidth at -20dB nm - - 4.5
Wavelength Resolution nm - - 0.01
Wavelength Accuracy nm -0.1 - 0.1
Temperature Dependence pm / ºC - 2 -
Power Monitor Relative Accuracy*1 dB -0.1 - 0.1
PDL dB - 0.1 0.2
PMD*3 ps - - 0.1
Return Loss dB 45 50 -
Max.Optical Input Power*2 dBm - - 20
Fiber Type -
Connector Type -
Communication Interface -
Size (w x h x d) mm
Weight kg
Supply Voltage V
Maximum Power VA
Operating Temperature ºC
Operating Humidity %
Operating Height above sea level m
Storage Temperature ºC 0 - 50
Storage Humidity %
Polution Degree **
*1 Output Power : -20 ~ +10dBm *2 Damage Threshold *3 Design Guaranteed Performance
FC/SPC (FC/APC, SC/SPC, SC/APC options)
SMF
12-S2: 12 Type, Single Cavity, Double Cascade
AC100~240V ±10%
4
210 x 80 x 300
Item Unit
GPIB, RS-232C
2
35
<2000
<80 (Non condensing)
20 to 30
<80 (Non condensing)
Value
