Section 1 Maintenance
SCC1000C Crawler Crane — Maintenance Manual
4�4 Air Intake System
Air Intake System
Air intake manifold
Intercollant
Connecting pipe
Compressor
Air lter
Pressure
booster
Turbo
machine
Exhale manifold
Exhaust valve
Cylinder combustion
Air intake valve
Mufer
4.4.1 Air Intake System Diagram
Precautions of the air intake system:
1. Check the air intake piping daily for leaks or cracks in piping, or loose clamp.
2. Remove the dust in the collector of air lter.
3. Visually inspect the warning indicator indicating air intake blockage in air lter every day. Clean the lter
element of air lter if it is blocked or even replace the lter element with a new one as necessary.
4. Use the lter element and safety lter element as designated. Otherwise, it will cause engine premature
wear.
T103 7010
T103 7016
Engine air intake pipe
Air prelter
Air lter
Flow Chart of Air Inlet (Outlet) System
