SANY SCC1000C - Slewing Reducer (Kawasaki); 6�1 Slewing Reducer - Checking the Oil Level

- 74/250 -
Section 1 Maintenance
SCC1000C Crawler Crane — Maintenance Manual
CAUTION
CAUTION
□
6 Slewing Reducer (Kawasaki)
Select the appropriate slewing reducer
according to actual configuration of the
crane�
6�1 Slewing Reducer - Checking the Oil
Level
-- Operation of refilling lubricating oil Refer to 6.2
Changing Oil.
-- Part the crane on a horizontal surface, and
remove the dipstick or the oil lling plug. If the oil
surface reaches the mark of the dipstick or can
be seen at the lling hole, the oil is sufcient.
If any oil leaks are found during checking
the oil level, the opera tion must be
temporarily stopped, and the system
should be disassembled for examination�
Structure and Mounting Position of Slewing Reducer
Oil dipstick
Oil drain
plug
Slewing
motor
Slewing
reducer
Platform
Base
Oil dipstick
Oil lling
plug
T103 5006
T103 5007
Checking Oil Level
