SANY SCC1000C - Slewing Bearing; 5�1 Lubricating Inside of the Slewing Bearing; Structure of the Slewing Bearing

- 68/250 -
Section 1 Maintenance
SCC1000C Crawler Crane — Maintenance Manual
5 Slewing Bearing
5�1 Lubricating inside of the Slewing Bearing
5�1�1 Structure of the Slewing Bearing
Slewing Mechanism (Rexroth )
Slewing center
1 Bolt 8 Dust cap
2 Washer 9 Bolt
3 Lubricating pipeline 10 Washer
4 Slew ring 11 Washer
5 Bolt 12 Bolt
6 Nut 13 Washer
7 Slewing reducer
T103 5001
