SANY SCC1000C - Engine System (Tier Ⅱ); 4�1 Engine

- 50/250 -
Section 1 Maintenance
SCC1000C Crawler Crane — Maintenance Manual
□
4 Engine System (Tier
Ⅲ
)
4�1 Engine
Refer to the maintenance instructions and
precautions of engine in the operating instructions
provided by the engine manufacture.
While preparing the motor for cleaning, must
make sure that:
1. During the cleaning process, water injection
spray should not directly point to the starting
motor and the engine.
2. Before cleaning, disassemble the starting motor
with the bearing opening facing downwards.
Burning and scalding hazard� Maintenance
in the engine area should be subject to the
rule of cooling for 60 minutes after shut-off�
Structure of Engine System (Tier
Ⅲ
)
Engine oil lling port
Fuel drain port
Fuel lling port
Fuel lter
Engine oil level meter
Engine drain port
Bent axis
T103 7013
Use the light diesel in compliance with
GB252-2000 and carry out periodic
maintenance as per the maintenance
instructions provided by the engine
manufacturer� The engine manufacturer
will take no responsibility for any engine
fuel system fault caused by use of
improper diesel�
CAUTION
CAUTION
