MENU FLOW CHART AND MENU
OPERATIONS
MENU flow
<MAIN MENU 1>
1.LANGUAGE/CLOCK SET ->
2.VIDEO INPUT SET ->
3.RECORDING AREA SET ->
4.RECORDING CONDITIONS SET ->
5.NORMAL REC MODE SET ->
6.TIMER SET ->
7.HOLIDAY SET ->
8.ALARM REC MODE SET ->
TO MAIN MENU 2 ->
MOVE LINES WITH JOG. SELECT WITH SHUTTLE
<LANGUAGE/LANGUE/IDIOMA>
ENGLISH
<CLOCK SET>
01-01-2002 TUE 00:00:00
<DAYLIGHT SAVING>
MODE : USE
WEEK MONTH TIME
ON 1ST-SUN 04 02:00
OFF LST-SUN 10 02:00
<EXT.CLOCK SET>
ADJUST.TIME 01:00
<VIDEO INPUT SET>
MULTIPLEXER : NO USE
VIDEO INPUT : ANALOG
<NORMAL REC MODE SET>
PICTURE QUALITY : ENHANCED
FRAME/FIELD RECORDING : FIELD
AUDIO RECORDING : OFF
REC CYCLE : 0.10 SEC ( 54H)
<HOLIDAY SET>
1. ----- 11. -----
2. ----- 12. -----
3. ----- 13. -----
4. ----- 14. -----
5. ----- 15. -----
6. ----- 16. -----
7. ----- 17. -----
8. ----- 18. -----
9. ----- 19. -----
10. ----- 20. -----
<DISPLAY SET>
DATE : ON
TIME : ON
QUALITY : ON
REC CYCLE : ON
ALARM COUNT : ON
ALARM TYPE : ON
<VIDEO LOSS SET>
VIDEO LOSS : ON
<SECURITY LOCK SET>
LEVEL PASSWORD(4-8) USE
ADMIN -------- OFF
USER -------- OFF
REC CONTROL : ADMIN
<NETWORK SET>
LAN CARD : LAN1
NETWORK CONTROL : OFF
IP ADDRESS : 192.168. 0. 1
SUBNET MASK : 255.255.255. 0
GATEWAY : 0. 0. 0. 0
PORT : 00080
ID : PASSWORD (4-8)
ID1 : 1111----
ID2 : 2222----
ID3 : 3333----
<POWER FAILURE/USED TIME>
POWER FAILURE
#003 FAILURE ----- --:--
RECOVER ----- --:--
USED TIME
DISK1 USE : 00000H
DISK2 USE : -----H
POWER : 00000H
FIRMWARE : MAIN 1.00-00 / SUB 1.00-00
<MAIN MENU 2>
1.DISPLAY/VIDEO LOSS SET ->
2.RS-232C/RS-485 SET ->
3.BUZZER SET ->
4.SECURITY LOCK SET ->
5.NETWORK SET ->
6.HDD SET ->
7.POWER FAILURE/USED TIME ->
TO MAIN MENU 1 ->
MOVE LINES WITH JOG. SELECT WITH SHUTTLE
<RECORDING AREA SET>
TOTAL CAPACITY : 80GB
NORMAL RECORDING AREA : 80 %
AREA FULL RESET ->
ALARM RECORDING AREA : 19 %
AREA FULL RESET ->
ARCHIVE AREA : 1 %
AREA FULL RESET ->
CAUTION : WHEN THE AREA SETTING IS CHANGED.
THE WHOLE AREA WILL BE INITIALIZED !
<RECORDING CONDITIONS SET>
DIGITAL SERIES RECORDING : OFF
TOTAL NUMBER : ¤¤
RECORDING NUMBER : ¤¤
NORMAL RECORDING AREA
OVERWRITE : ON
ALARM RECORDING AREA
OVERWRITE : ON
REMAINING DISK WARNING : ¤¤
<TIMER SET>
WEEK START STOP REC CYCLE SET
SUN --:-- --:-- 0.10SEC ( 54H) OFF
MON --:-- --:-- 0.10SEC ( 54H) OFF
TUE --:-- --:-- 0.10SEC ( 54H) OFF
WED --:-- --:-- 0.10SEC ( 54H) OFF
THU --:-- --:-- 0.10SEC ( 54H) OFF
FRI --:-- --:-- 0.10SEC ( 54H) OFF
SAT --:-- --:-- 0.10SEC ( 54H) OFF
DLY --:-- --:-- 0.10SEC ( 54H) OFF
<ALARM REC MODE SET>
PICTURE QUALITY :
ENHANCED
FRAME/FIELD RECORDING : FIELD
AUDIO RECORDING : OFF
ALARM RECORDING : OFF
REC CYCLE : 0.10SEC. DURATION: 1SEC
PRE-ALARM RECORDING : ¤¤¤
REC CYCLE : ¤¤¤ SEC. DURATION: ¤¤¤
=> (46400 ALARMS CAN BE RECORDED)
ALARM TRIGGER : ALARM
MOTION SENSOR ->
<RS-232C/RS-485 SET>
CONTROL : RS-232C
DATA SPEED : 19200
STATUS INFO : ¤¤¤
ALARM INFO : ¤¤¤
ADDRESS : ¤¤¤
<BUZZER SET>
ALARM : OFF
DISK FULL : ON
DISK ERROR : ON
LOCK WARNING : ON
KEY IN : OFF
NON REC : OFF
<HDD SET>
DISK1 : 80GB
DISK2 : ---GB
DISK INITIALIZE ->
CAUTION : ALL RECORDING WILL BE ERASED!
MIRRORING : OFF
PLAYBACK DRIVE : ¤¤¤
CAUTION : RECORDING SPEED WILL BE
LIMITED BY MIRRORING!
Settings for recording Settings for operating environment
Main menu 1
Sub-menus
Main menu 2
Main menu 1 contains settings that deal mainly with recording. Main menu 2 contains settings that deal mainly with the
operating environment.
b Language, clock and daylight
saving settings (See page 42, 43.)
b Normal recording area
settings (See page 49.)
b Multiplexer and video input
settings (See page 44.)
b Timer settings
(See page 50.)
b Recording area settings
(See page 45.)
b Holiday settings
(See page 53.)
b Recording settings
(See page 47.)
b Alarm recording settings
(See page 54.)
b Operating display settings
(See page 59.)
b Network settings
(See page 66.)
b
RS-232C/RS-485 communication
settings (See page 60.)
b Hard disk settings
(See page 69.)
b Buzzer settings
(See page 62.)
b Security lock settings
(See page 63.)
b Power failure/used time
settings (See page 70.)
40
English
