POWER FAILURE/USED TIME DISPLAY
1
Press the MENU button twice to display the MAIN MENU 2
screen.
The cursor moves to DISPLAY/VIDEO LOSS SET.
2
Use the jog dial to move the cursor to the POWER
FAILURE/USED TIME settings, and then turn the shuttle dial
clockwise.
The POWER FAILURE/USED TIME sub-menu appears.
Check the date/time of a power failure or the usage time of hard
disks, etc.
3
Press the EXIT/OSD button.
The display returns to the normal screen.
About the sub-menu
1
FAILURE
Shows the date/time when a power failure occurred.
The number of power failures appears at the left. (example: #020)
When the number exceeds 999 it returns to 000.
2
RECOVER
Shows the date/time when power was restored.
3
DISK1 USE
Shows the total hard disk 1 usage time.
4
DISK2 USE
Shows the total hard disk 2 usage time.
5
POWER
Shows the total usage time for this unit.
6
FIRMWARE
Shows the current firmware version.
<MAIN MENU 2>
1.DISPLAY/VIDEO LOSS SET ->
2.RS-232C/RS-485 SET ->
3.BUZZER SET ->
4.SECURITY LOCK SET ->
5.NETWORK SET ->
6.HDD SET ->
7.POWER FAILURE/USED TIME ->
TO MAIN MENU 1 ->
MOVE LINES WITH JOG. SELECT WITH SHUTTLE
Main menu 2
<POWER FAILURE/USED TIME>
POWER FAILURE
#020 FAILURE ----- --:--
RECOVER ----- --:--
USED TIME
DISK1 USE : 00000H
DISK2 USE : -----H
POWER : 00000H
FIRMWARE : MAIN 1.00-00 / SUB 1.00-00
Sub-menus
1
2
3
5
4
6
MENU
<POWER FAILURE/USED TIME>
POWER FAILURE
#001 FAILURE 06-15 20:30
RECOVER 06-15 21:30
USED TIME
DISK1 USE : 00060H
DISK2 USE : -----H
POWER : 00060H
FIRMWARE : MAIN 1.00-00 / SUB 1.00-00
EXIT/OSD
70
