Sanyo PLC-SU50 Service Manual

PH3-SL2000, PG3-XL2000
-31-
Electrical Parts List
Q682 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q6841 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q6842 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q6843 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q6844 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q69A 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q691 405 154 3301 TR 2SK3280-TL
Q8141 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q8142 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q8143 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q8151 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q856 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q9801 405 134 5905 TR 2SA1037AK-T146-R
INTEGRATED CIRCUIT
IC1201 409 530 7204 IC AN5870SB
IC1281 409 493 2902 IC SI-3012LU-TL
IC1301 410 325 4605 IC TC74LCX244FT
IC1311 409 350 2908 IC TC7W126FU-(TE12L)
IC1321 409 501 9107 IC ICS512MT
IC1331 409 501 9107 IC ICS512MT
IC1341 409 533 6006 IC 24LC32AT-I/SN
IC1351 409 301 5309 IC TC7S32FU-TE85L
IC1381 410 493 4506 IC MBM29DL32TF70C347
(PH3-SL2000)
IC1381 410 500 6301 IC MBM29DL32TF70C375
(PG3-XL2000)
IC1391 410 478 4804 IC IDT71V30S25TF
IC1451 410 403 7900 IC LC24085BT-UG4
IC1801 409 339 3605 IC 24LC16BT/SN-T
IC1811 410 490 4202 IC M5M5V108DKV
410 490 8903 IC N01L083WC2AN
IC1841 409 350 2908 IC TC7W126FU-(TE12L)
IC1851 409 404 6302 IC M62320FP
IC1861 410 337 0503 IC TC74LCX14FT
410 337 0602 IC HD74LVC14T
IC1881 410 315 5506 IC HD74HCT244TV
410 356 7507 IC SN74HCT244PWR
IC201 410 476 5605 IC AD9882KST-100
(PH3-SL2000)
IC201 410 476 5506 IC AD9882KST-140
(PG3-XL2000)
IC2101 409 504 5007 IC TC90A69F
IC2311 410 356 7606 IC SN74AHC1G04HDCKR
IC2312 410 381 4403 IC TC7W32FU(TE12L)
IC2321 410 362 6501 IC TC74LCX541FT
IC2322 410 362 6501 IC TC74LCX541FT
IC2323 410 346 8804 IC TC74LCX574FT
IC2324 410 346 8804 IC TC74LCX574FT
IC2341 410 339 4103 IC TC74LCX245FT
IC2342 410 339 4103 IC TC74LCX245FT
IC2343 409 429 2808 IC TC74LCX04FT-(EL)
IC2351 409 400 7105 IC TC7W53FU-(TE12L)
IC2352 409 400 7105 IC TC7W53FU-(TE12L)
IC2353 409 334 0104 IC TC7W125FU
IC2371 409 462 2407 IC TC7SZ08FU-(TE85L)
IC2801 409 481 8602 IC LM76CHMX-5
IC281 409 458 3401 IC M62393FP
Key No. Part No. Description Key No. Part No. Description
