Sanyo PLC-SU50 Service Manual

PH3-SL2000, PG3-XL2000
Electrical Parts List
-32-
IC2831 409 481 8602 IC LM76CHMX-5
IC2861 409 481 8602 IC LM76CHMX-5
IC301 409 558 5909 IC PW463A-10V
IC3101 409 504 9005 IC TB1274AF
IC3102 409 416 6505 IC BA05FP-E2
IC3103 409 416 6505 IC BA05FP-E2
IC3871 409 466 6906 IC SP232ECT
IC401 409 554 1301 IC L3E07070K0A
IC411 409 422 5806 IC M62398FP
IC412 409 124 5906 IC L78M12T-TL
IC4891 409 404 7200 IC TC7SET00FU-(TE85L)
IC491 409 555 6404 IC SI-3018KS-TL
IC501 409 554 1202 IC L3E06100D0A
IC511 409 246 9707 IC LA6358NM-TE-L
IC5201 409 530 7204 IC AN5870SB
IC5301 409 434 8109 IC TC4053BFT-(EL)
IC531 409 554 1202 IC L3E06100D0A
IC5341 409 484 2003 IC BA7078AF-E2
IC5351 409 545 7503 IC TA1370FG
IC5361 410 471 9905 IC SN74AHC2G14HDCTR
IC5371 410 315 5506 IC HD74HCT244TV
410 356 7507 IC SN74HCT244PWR
IC561 409 554 1202 IC L3E06100D0A
IC6211 409 506 0406 IC M62392FP
IC6621 409 124 5708 IC L78M09T-TR
IC6631 409 416 6406 IC BA033FP-E2
IC6641 409 416 6406 IC BA033FP-E2
IC6651 409 416 6406 IC BA033FP-E2
IC6671 409 499 1701 IC PQ025EZ01ZP
IC6681 409 416 6505 IC BA05FP-E2
IC671 409 531 6206 IC FA7701V-TE1
IC681 409 531 6206 IC FA7701V-TE1
IC801 410 493 4407 IC HD64F2238ATE13-C346
IC8101 409 434 8109 IC TC4053BFT-(EL)
IC8111 409 417 5507 IC 24LC04BT/SN
IC8121 409 434 8109 IC TC4053BFT-(EL)
IC8131 409 417 5507 IC 24LC04BT/SN
IC8141 409 451 2807 IC TC7W66FK-(TE85L)
IC8151 409 434 8109 IC TC4053BFT-(EL)
IC8161 NOTSUPPLIED PARTS
IC841 409 433 4201 IC MN13821-H-TX
IC9801 409 468 8908 IC ML60851CTB
409 521 4502 IC ML60851DTB
IC9882 409 464 1408 IC TC74ACT14FT
CAPACITOR
C1201 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C1202 403 283 6309 CERAMIC 1U Z 10V
C1203 403 355 9900 CERAMIC 2.2U K 10V
C1204 403 355 9900 CERAMIC 2.2U K 10V
C1207 403 355 9900 CERAMIC 2.2U K 10V
C1208 403 355 9900 CERAMIC 2.2U K 10V
C1209 403 164 0204 CERAMIC 0.1U Z 25V
C1231 403 355 9900 CERAMIC 2.2U K 10V
C1233 403 355 9900 CERAMIC 2.2U K 10V
C1234 403 164 0204 CERAMIC 0.1U Z 25V
C1241 403 164 0204 CERAMIC 0.1U Z 25V
C1242 403 348 5803 CERAMIC 0.47U K 10V
C1243 403 149 9208 CERAMIC 0.01U Z 50V
C1244 403 149 9208 CERAMIC 0.01U Z 50V
C1246 403 280 1604 ELECT 220U M 16V
C1247 403 149 9208 CERAMIC 0.01U Z 50V
C1248 403 280 1604 ELECT 220U M 16V
C1249 403 149 9208 CERAMIC 0.01U Z 50V
C1251 403 321 7503 ELECT 220U M 16V
C1282 403 321 7404 ELECT 100U M 16V
C1283 403 164 0204 CERAMIC 0.1U Z 25V
C1301 403 164 0204 CERAMIC 0.1U Z 25V
C1311 403 164 0204 CERAMIC 0.1U Z 25V
C1321 403 304 1801 ELECT 100U M 6.3V
403 373 7704 ELECT 100U M 6.3V
C1322 403 164 0204 CERAMIC 0.1U Z 25V
C1332 403 164 0204 CERAMIC 0.1U Z 25V
C1341 403 164 0204 CERAMIC 0.1U Z 25V
C1342 403 164 0204 CERAMIC 0.1U Z 25V
C1351 403 164 0204 CERAMIC 0.1U Z 25V
C1352 403 164 0204 CERAMIC 0.1U Z 25V
C1381 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C1391 403 164 0204 CERAMIC 0.1U Z 25V
C1451 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C1452 403 164 0204 CERAMIC 0.1U Z 25V
C1453 403 164 0204 CERAMIC 0.1U Z 25V
C1454 403 164 0204 CERAMIC 0.1U Z 25V
C1456 403 164 0204 CERAMIC 0.1U Z 25V
C1457 403 164 0204 CERAMIC 0.1U Z 25V
C1458 403 164 0204 CERAMIC 0.1U Z 25V
C1459 403 164 0204 CERAMIC 0.1U Z 25V
C1461 403 164 0204 CERAMIC 0.1U Z 25V
C1462 403 164 0204 CERAMIC 0.1U Z 25V
C1464 403 164 0204 CERAMIC 0.1U Z 25V
C1466 403 164 0204 CERAMIC 0.1U Z 25V
C1801 403 304 1801 ELECT 100U M 6.3V
403 373 7704 ELECT 100U M 6.3V
C1802 403 164 0204 CERAMIC 0.1U Z 25V
C1811 403 164 0204 CERAMIC 0.1U Z 25V
C1861 403 164 0204 CERAMIC 0.1U Z 25V
C1881 403 164 0204 CERAMIC 0.1U Z 25V
C201 403 164 0204 CERAMIC 0.1U Z 25V
C202 403 164 0204 CERAMIC 0.1U Z 25V
C203 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C204 403 164 0204 CERAMIC 0.1U Z 25V
C206 403 164 0204 CERAMIC 0.1U Z 25V
C207 403 164 0204 CERAMIC 0.1U Z 25V
C2101 403 149 9208 CERAMIC 0.01U Z 50V
C2102 403 149 9208 CERAMIC 0.01U Z 50V
C2103 403 304 1801 ELECT 100U M 6.3V
403 373 7704 ELECT 100U M 6.3V
C2104 403 164 0204 CERAMIC 0.1U Z 25V
C2106 403 149 9208 CERAMIC 0.01U Z 50V
C2107 403 149 9208 CERAMIC 0.01U Z 50V
C2108 403 283 6309 CERAMIC 1U Z 10V
C2109 403 304 2105 ELECT 47U M 6.3V
C211 403 164 0204 CERAMIC 0.1U Z 25V
C2111 403 304 2105 ELECT 47U M 6.3V
C2112 403 164 0204 CERAMIC 0.1U Z 25V
C2113 403 304 2105 ELECT 47U M 6.3V
C2114 403 164 0204 CERAMIC 0.1U Z 25V
C2116 403 164 0204 CERAMIC 0.1U Z 25V
C2117 403 304 2105 ELECT 47U M 6.3V
C2118 403 164 0204 CERAMIC 0.1U Z 25V
C2119 403 164 0204 CERAMIC 0.1U Z 25V
C212 403 164 0204 CERAMIC 0.1U Z 25V
C2121 403 305 9905 CERAMIC 680P J 25V
C2122 403 149 9208 CERAMIC 0.01U Z 50V
C2123 403 149 9208 CERAMIC 0.01U Z 50V
C213 403 164 0204 CERAMIC 0.1U Z 25V
C2131 403 139 7108 CERAMIC 12P J 50V
C2132 403 157 1904 CERAMIC 10P D 50V
C2133 403 157 2505 CERAMIC 27P J 50V
C2134 403 139 7108 CERAMIC 12P J 50V
C2135 403 157 2505 CERAMIC 27P J 50V
Key No. Part No. Description Key No. Part No. Description
