Sanyo PLC-SU50 Service Manual

PH3-SL2000, PG3-XL2000
-33-
Electrical Parts List
C214 403 157 2901 CERAMIC 47P J 50V
C2141 403 139 7108 CERAMIC 12P J 50V
C2142 403 157 1904 CERAMIC 10P D 50V
C2143 403 157 2505 CERAMIC 27P J 50V
C2145 403 145 9905 CERAMIC 22P J 50V
C2146 403 304 3102 ELECT 22U M 16V
C2148 403 364 5801 CERAMIC 1U K 10V
C2150 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C216 403 205 2808 CERAMIC 0.047U K 25V
C217 403 164 0204 CERAMIC 0.1U Z 25V
C218 403 157 2901 CERAMIC 47P J 50V
C219 403 205 2808 CERAMIC 0.047U K 25V
C221 403 164 0204 CERAMIC 0.1U Z 25V
C222 403 157 2901 CERAMIC 47P J 50V
C223 403 205 2808 CERAMIC 0.047U K 25V
C224 403 164 0204 CERAMIC 0.1U Z 25V
C226 403 283 2905 CERAMIC 0.082U K 16V
C227 403 215 2102 CERAMIC 8200P K 50V
C228 403 164 0204 CERAMIC 0.1U Z 25V
C229 403 164 0204 CERAMIC 0.1U Z 25V
C231 403 164 0204 CERAMIC 0.1U Z 25V
C2311 403 283 6309 CERAMIC 1U Z 10V
C2312 403 164 0204 CERAMIC 0.1U Z 25V
C232 403 164 0204 CERAMIC 0.1U Z 25V
C2321 403 164 0204 CERAMIC 0.1U Z 25V
C2323 403 164 0204 CERAMIC 0.1U Z 25V
C233 403 164 0204 CERAMIC 0.1U Z 25V
C2341 403 164 0204 CERAMIC 0.1U Z 25V
C2351 403 164 0204 CERAMIC 0.1U Z 25V
C236 403 164 0204 CERAMIC 0.1U Z 25V
C237 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C238 403 164 0204 CERAMIC 0.1U Z 25V
C239 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C2391 403 379 9801 CERAMIC 10U K 6.3V
C2501 403 304 2105 ELECT 47U M 6.3V
C2511 403 229 3508 ELECT 100U M 16V
403 335 0408 ELECT 100U M 16V
C2512 403 164 0204 CERAMIC 0.1U Z 25V
C2513 403 164 0204 CERAMIC 0.1U Z 25V
C2514 403 379 6701 CERAMIC 10U K 16V
C2515 403 113 3805 CERAMIC 1000P K 50V
C2516 403 164 0204 CERAMIC 0.1U Z 25V
C2517 403 164 0204 CERAMIC 0.1U Z 25V
C2519 403 304 3300 ELECT 47U M 16V
C2521 403 164 0204 CERAMIC 0.1U Z 25V
C2531 403 379 6701 CERAMIC 10U K 16V
C2532 403 164 0204 CERAMIC 0.1U Z 25V
C2533 403 164 0204 CERAMIC 0.1U Z 25V
C2534 403 164 0204 CERAMIC 0.1U Z 25V
C2535 403 113 3805 CERAMIC 1000P K 50V
C2537 403 164 0204 CERAMIC 0.1U Z 25V
C2538 403 304 3300 ELECT 47U M 16V
C2571 403 164 0204 CERAMIC 0.1U Z 25V
C2572 403 379 6701 CERAMIC 10U K 16V
C2573 403 164 0204 CERAMIC 0.1U Z 25V
C2574 403 164 0204 CERAMIC 0.1U Z 25V
C2575 403 113 3805 CERAMIC 1000P K 50V
C2577 403 304 3300 ELECT 47U M 16V
C2578 403 164 0204 CERAMIC 0.1U Z 25V
C2801 403 164 0204 CERAMIC 0.1U Z 25V
C2802 403 155 1609 CERAMIC 33P J 50V
C2803 403 155 1609 CERAMIC 33P J 50V
C2804 403 164 0204 CERAMIC 0.1U Z 25V
C2806 403 155 1609 CERAMIC 33P J 50V
C2807 403 155 1609 CERAMIC 33P J 50V
C2808 403 164 0204 CERAMIC 0.1U Z 25V
C2809 403 155 1609 CERAMIC 33P J 50V
C281 403 304 2105 ELECT 47U M 6.3V
C2811 403 155 1609 CERAMIC 33P J 50V
C282 403 164 0204 CERAMIC 0.1U Z 25V
C283 403 304 2105 ELECT 47U M 6.3V
C284 403 164 0204 CERAMIC 0.1U Z 25V
C2891 403 164 0204 CERAMIC 0.1U Z 25V
C2892 403 157 2901 CERAMIC 47P J 50V
C301 403 139 7306 CERAMIC 18P J 50V
C302 403 139 7306 CERAMIC 18P J 50V
C306 403 164 0204 CERAMIC 0.1U Z 25V
C307 403 164 0204 CERAMIC 0.1U Z 25V
C308 403 164 0204 CERAMIC 0.1U Z 25V
C309 403 164 0204 CERAMIC 0.1U Z 25V
C3101 403 164 0204 CERAMIC 0.1U Z 25V
C3102 403 164 0204 CERAMIC 0.1U Z 25V
C3103 403 164 0204 CERAMIC 0.1U Z 25V
C3104 403 149 9208 CERAMIC 0.01U Z 50V
C3106 403 304 2105 ELECT 47U M 6.3V
C3107 403 343 8809 CERAMIC 0.47U Z 16V
C3108 403 304 2105 ELECT 47U M 6.3V
C3109 403 343 8809 CERAMIC 0.47U Z 16V
C311 403 164 0204 CERAMIC 0.1U Z 25V
C3111 403 164 0204 CERAMIC 0.1U Z 25V
C3112 403 164 0204 CERAMIC 0.1U Z 25V
C3113 403 164 0204 CERAMIC 0.1U Z 25V
C3114 403 162 5300 ELECT 4.7U M 25V
C3116 403 304 2105 ELECT 47U M 6.3V
C3117 403 164 0204 CERAMIC 0.1U Z 25V
C312 403 164 0204 CERAMIC 0.1U Z 25V
C3121 403 157 1706 CERAMIC 8P D 50V
C3122 403 164 0204 CERAMIC 0.1U Z 25V
C3123 403 149 9208 CERAMIC 0.01U Z 50V
C3124 403 162 6000 ELECT 0.47U M 50V
C3126 403 164 0204 CERAMIC 0.1U Z 25V
C3127 403 149 9208 CERAMIC 0.01U Z 50V
C3128 403 164 0204 CERAMIC 0.1U Z 25V
C3129 403 164 0204 CERAMIC 0.1U Z 25V
C313 403 164 0204 CERAMIC 0.1U Z 25V
C3131 403 284 4304 CERAMIC 0.022U K 50V
C3132 403 162 6604 ELECT 2.2U M 50V
C3133 403 113 3805 CERAMIC 1000P K 50V
C3134 403 157 2901 CERAMIC 47P J 50V
C3135 403 322 7809 ELECT 220U M 6.3V
403 349 4706 ELECT 220U M 6.3V
C3136 403 164 0204 CERAMIC 0.1U Z 25V
C3137 403 164 0204 CERAMIC 0.1U Z 25V
C3138 403 341 3905 POS-SOLID 100U M 6.3V
C314 403 164 0204 CERAMIC 0.1U Z 25V
C3144 403 164 0204 CERAMIC 0.1U Z 25V
C3151 403 157 3106 CERAMIC 56P J 50V
C316 403 164 0204 CERAMIC 0.1U Z 25V
C317 403 164 0204 CERAMIC 0.1U Z 25V
C3171 403 283 6309 CERAMIC 1U Z 10V
C3172 403 164 0204 CERAMIC 0.1U Z 25V
C3176 403 164 0204 CERAMIC 0.1U Z 25V
C3177 403 164 0204 CERAMIC 0.1U Z 25V
C3178 403 164 0204 CERAMIC 0.1U Z 25V
C318 403 164 0204 CERAMIC 0.1U Z 25V
C3181 403 321 2607 ELECT 10U M 16V
C3182 403 215 2201 CERAMIC 0.01U K 50V
C319 403 164 0204 CERAMIC 0.1U Z 25V
C3191 403 145 9905 CERAMIC 22P J 50V
C3192 403 157 1904 CERAMIC 10P D 50V
C3193 403 157 2901 CERAMIC 47P J 50V
Key No. Part No. Description Key No. Part No. Description
