8
Safety Instructions
Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in severe
accident or fire hazard.
This projector can project the picture upward, downward, or backward, perpendicular to the plane of the screen as
shown in the figure below.
Bottom
Downward
(Usual)
Front
Downward
Bottom
Upward
Front
Upward
Installing the Projector in Proper Directions
Avoid positioning the projector as described below when installing.
Positioning Precautions
Do not tilt the projector more than 10 degrees from side to side.
Do not put the projector on either side to project an image.
Ý
Ý
10ÝÝ
10Ý
10Ý
In upward projection, do not tilt the projector over 10 degrees right and left.
In downward projection, do not tilt the projector over 10 degrees right and left.
Fan Control
"Max"
Fan Control
"Normal"
0º
180º
40º
50º50º
40º
Be sure to set the Fan control in MAX in the setting menu when
the projector is inclined between +40 degrees to +140 degrees
to the horizontal plane (p.56).
