-10-
x Main Board, Rear Panel, Fan(FN905), SP901 removal
Mechanical Disassembly
Main board
Rear panel
FN905
SP901
(M2.5x6)x8
(M4x5)
(T3x8)
Fig.2
Grounding
lead
(M2.5x6)x2
